3-30
Instruments and controls/Warning and indicator lights
& Select lever/gear position indicator
If the indicator lights do not blink or blink
rapidly, the turn signal bulb may be burned
out. Replace the bulb as soon as possible.
Refer to “Replacing bulbs” F11-40.
& High beam indicator
light
This light shows that the headlights are in
the high beam mode.
This indicator light also illuminates when
the headlight flasher is operated.
& Cruise control indicator light
1)
2)
Upshift indicator
Downshift indicator
This indicator shows the position of the
select lever.
When the manual mode is selected, the
gear position indicator (which shows the
current gear selection) and the upshift/
downshift indicator light up. Refer to
“Continuously variable transmission” F714.
& Turn signal indicator
lights
These lights show the operation of the turn
signal or lane change signal.
This light illuminates when the cruise
control main button is pressed to activate
the cruise control function. For details,
refer to “To set cruise control” F7-33.
& Cruise control set indicator light
This light illuminates when vehicle speed
has been set to use the cruise control
function. Refer to “To set cruise control”
F7-33.
& Automatic headlight
beam leveler warning
light (models with HID
headlights)
This light illuminates when the automatic
headlight beam leveler does not operate
normally.
If this light illuminates while driving or does
not GW&
