3-18

Instruments and controls/Warning and indicator lights

level or adding the engine oil, refer to
“Engine oil” F11-10.

CAUTION
Do not operate the hybrid system
with the oil pressure warning light
illuminated. This may cause serious
engine damage.

& Engine low oil level
warning light

This light illuminates when the engine oil
level decreases to the lower limit.
If the engine low oil level warning light
illuminates while driving, park the vehicle
in a safe and level location, and then
check the engine oil level. When the
engine oil level is not within the normal
range, refill with engine oil. Refer to
“Engine oil” F11-10.
If the warning light does not turn off after
refilling the engine oil, or the warning light
illuminates even though the engine oil
level is within the normal range, have the
vehicle checked by a SUBARU dealer.

NOTE
. After replacing or adding the engine
oil, if the engine oil level is within the
normal range when restarting the hy-

brid system on a level surface, the
warning light will turn off.
. The warning light may illuminate
temporarily in the following conditions
because a low oil level may be detected
as a result of significant oil movement
in the engine.
– when the vehicle is considerably
inclined on an uphill or steep slope
– when the vehicle has continuously accelerated and decelerated
– when the vehicle is continuously
turned
– when the vehicle is driven on a
road that alternates continuously
between uphill and downhill

& Windshield washer
fluid warning light

This light illuminates when the fluid level in
the windshield washer fluid tank decreases to the lower limit (approximately
1.1 US qt, 1.0 liter, 0.9 Imp qt).

& AT OIL TEMP warning
light

If this light illuminates when the hybrid
system is running, it may indicate that the
transmission fluid temperature is too hot.
If the light illuminates while driving, im-

mediately stop the vehicle in a safe place
and let the hybrid system idle until the
warning light turns off.
! Transmission control system warning
If the “AT OIL TEMP” warning light flashes
after the hybrid system has started, it may
indicate that the transmission control
system is not working properly. Contact
your nearest SUBARU dealer for service
immediately.

& Low tire pressure

warning light (U.S.-spec.
models)
