Instruments and controls/Warning and indicator lights

overheating. After that, have
the system checked by your
nearest SUBARU dealer. Refer
to “Engine overheating” F917.
– Blinking in RED and BLUE
alternately:
The electrical system may be
malfunctioning. Contact your
SUBARU dealer for an inspection.
This coolant temperature low indicator
light/coolant temperature high warning
light has the following three functions.
. Illumination in BLUE indicates insufficient warming up of the engine
. Blinking in RED indicates that the
engine is close to overheating
. Illumination in RED indicates overheating condition of the engine
For a system check, this indicator light/
warning light illuminates in RED for
approximately 2 seconds when the ignition switch is turned to the “ON” position.
After that, this indicator light/warning light
changes to BLUE and maintains illumination in BLUE. This BLUE illuminated light
turns off when the engine is warmed up
sufficiently.

If the engine coolant temperature increases over the specified range, the
indicator light/warning light blinks in
RED. At this time, the engine is close to
overheating.
If the engine coolant temperature increases further, the indicator light/warning
light illuminates in RED continuously. At
this time, the engine may be overheating.
When the indicator light/warning light
blinks in RED or illuminates in RED, safely
stop the vehicle as soon as possible, and
refer to the emergency steps to take in the
case of engine overheating. Refer to
“Engine overheating” F9-17. After that,
have the system checked by your nearest
SUBARU dealer.
Also, if the indicator light/warning light
often blinks in RED, the electrical system
may be malfunctioning. Contact your
SUBARU dealer for an inspection.

NOTE
If the engine is restarted after a certain
driving condition, this indicator light/
warning light may illuminate in RED.
However, this is not a malfunction if the
indicator light/warning light turns off
after a short time.

3-17

& Charge warning light
If this light illuminates when the hybrid
system is running, it may indicate that the
charging system of the 12 V auxiliary
battery and 12 V engine restart battery is
not working properly.
If the light illuminates while driving or does
not turn off after the hybrid system starts,
stop the hybrid system at the first safe
opportunity and check the alternator belt.
If the belt is loose, broken or if the belt is in
good condition but the light remains
illuminated, contact your nearest
SUBARU dealer immediately.

& Oil pressure warning
light

If this light illuminates when the hybrid
system is running, it may indicate that the
engine oil pressure is low and the lubricating system is not working properly.
If the light illuminates while driving or does
not turn off after the hybrid system starts,
stop the hybrid system at the first safe
opportunity and check the engine oil level.
If the oil level is low, add oil immediately. If
the engine oil is at the proper level but the
light remains illuminated, contact your
nearest SUBARU dealer immediately.
For details about checking the engine oil
– CONTINUED –
