Instruments and controls/Meters and gauges
. It is not possible to change the initial
movement setting of the meter/gauge
needles when the ignition switch is in
the “ON” position. Change the setting
when the ignition switch is in the
“LOCK” (off) or “ACC” position.
& Meter/Gauge needle illumination setting
When the setting is activated or deactivated, the meter needles and gauge
needles illuminate and turn off as follows.
Activated:
When the driver’s door is opened while
the ignition switch is in the “LOCK” (off)
position, the needles illuminate and turn
off after approximately 20 seconds. The
illumination of the needles gradually turns
off after the ignition switch is turned from
the “ON” position to the “LOCK” (off)
position.
3-9
NOTE
. Even during the illumination after
the driver’s door is opened, if the
ignition switch is turned to the “ON”
position, the combination meter will
illuminate as usual.
. If the doors are locked by the remote
keyless entry system or keyless access function (if equipped) during the
illumination after the driver’s door is
opened, the illumination will be turned
off.
. Even while the illumination gradually turns off after the ignition switch is
turned to the “LOCK” (off) position, if
the ignition switch is turned to the
“ON” position, the combination meter
illuminate as usual.
To change the setting:
1. Turn the ignition switch to the “LOCK”
(off) or “ACC” position.
2. Press the trip knob to show “
” or
“
” on the odometer and trip meter
display. The display can be switched as
shown in the following illustration by
pressing the trip knob.
Deactivated:
The needles do not illuminate when the
driver’s door is opened while the ignition
switch is in the “LOCK” (off) position. The
illumination of the needles turns off immediately after the ignition switch is turned
from the “ON” position to the “LOCK” (off)
position.
*: They cannot be displayed when the
ignition switch is in the “ON” position.
– CONTINUED –
