3-8
Instruments and controls/Meters and gauges
Meters and gauges
NOTE
Liquid-crystal displays are used in
some of the meters and gauges on
the combination meter. You will find
their indications hard to see if you wear
polarized glasses.
& Combination meter illumination
When the ignition switch is turned to the
“ON” position, the various parts of the
combination meter are illuminated in the
following sequence.
1. Warning lights, indicator lights, meter
needles, gauge needles and liquid crystal
display illuminate.
2. Meter and gauge indications each
show MAX position.
3. Meter and gauge indications each
show MIN position.
4. Regular illumination (for driving) begins.
& Canceling the function for
meter/gauge needle movement upon turning on the
ignition switch
The display can be switched as shown in
the following sequence by pressing the
trip knob.
It is possible to activate or deactivate the
movement of the meter needles and
gauge needles that takes place when the
ignition switch is turned to the “ON”
position. To change the setting, perform
the following procedure.
1. Turn the ignition switch to the “LOCK”
(off) or “ACC” position.
*: They cannot be displayed when the
ignition switch is in the “ON” position.
To change the current setting, press and
hold the knob for at least 2 seconds.
: Activated
: Deactivated
NOTE
1)
2)
Trip knob
Select knob
2. Press the trip knob or the select knob
to show “ ” or
