Emergency Response (Continued)
Extrication (Continued)
2. Remove the fuse box cover.
3. Remove the SBF No.14 fuse (30 A) in the engine compartment fuse box (refer to illustration). If
the correct fuse cannot be recognized, pull all fuses in the fuse box.
4. Disconnect the battery ground terminal of both the 12 Volt auxiliary battery and the 12 Volt
engine restart battery in the engine compartment.
Fuse Box Cover
SBF No.14 Fuse (30A) in Engine Compartment
Fuse Box
12 Volt Auxiliary Battery
12 Volt Engine Restart Battery
-33-
