■ Fuel Gauge
■ Engine Coolant Temperature Gauge
306783 The fuel gauge shows the approximate amount of fuel remaining in the tank.
When the ignition switch is in the“ OFF” or“ ACC” position, the fuel gauge shows“ E” even if the fuel tank contains fuel.
The gauge may move slightly due to fuel level movement in the tank( e. g., during braking, turning or acceleration).
NOTE
You will see the“” sign in the fuel gauge. This indicates that the fuel filler lid is located on the right side of the vehicle.
B02099
The temperature gauge shows engine coolant temperature when the ignition switch is in the“ ON” position.
The coolant temperature will vary in accordance with the outside temperature and driving conditions.
We recommend that you drive moderately until the pointer of the temperature gauge reaches near the middle of the range. Engine operation is optimum with the engine coolant at this temperature range and high revving operation when the engine is not warmed up enough should be avoided.
