When a door is closed, its window closes completely. However, if the battery has discharged or is disconnected, this function will not operate. � If the power window system detects resistance, an impact or abnormality, the window operation may be automatically stopped to prevent further jamming, entrapment or malfunction.- The closing window slides down slightly and stops.- The opening window stops sliding down. � The power window system may detect resistance, an impact or an abnormality in the following cases.- A substantial sized object is caught between the window and the roof side( between the front pillar and a point over the rear seat).- A foreign object is caught between the window and the roof side( between the front pillar and a point over the rear seat).- The vehicle drives over a deep pothole. � The window cannot be closed for a few seconds after the window is automatically stopped by the system.
■ Power Window Operation
▼ Power window switches � Driver’ s side power window switches: 3
1) |
For left window |
2) |
For right window |
3) |
Lock switch |
1 2
204137
All door windows can be controlled by the power window switch cluster on the driver side door.
