C ■ RAB OFF Indicator ( If Equipped )
This indicator illuminates when the Reverse Automatic Braking ( RAB ) System is turned OFF , or when the Reverse Automatic Braking ( RAB ) System is suspended temporarily . Refer to " Reverse Automatic Braking ( RAB ) System ( If Equipped )" �P273 . ■ Sonar Audible Alarm OFF Indicator ( If Equipped )
This indicator illuminates when the Sonar Audible Alarm function is turned OFF , or when the Sonar Audible Alarm function is suspended temporarily . Refer to " Reverse Automatic Braking ( RAB ) System ( If Equipped )" �P273 .
■ Master Warning Light
A buzzer sounds and the warning light comes on and flashes to indicate that the master warning system has detected a malfunction .
3-7 . Combination Meter Display ( Color TFT ) WARNING Always pay adequate attention to safe driving when operating the combination meter display ( color TFT ) while the vehicle is in motion . When operation of the combination meter display ( color TFT ) interferes with your ability to concentrate on driving , stop the vehicle before performing operations on the screen . Also , do not concentrate on the display while driving . Doing so may cause you to look away from the road and could result in an accident .
Various information will be shown on the combination meter display ( color TFT ). Also , a warning message will appear on the display if a malfunction is detected . In addition , several settings for the displayed content can be performed .
