130
REV indicator light and buzzer ■ Combination Meter Settings
Some meter settings can be set on the center information display . For details , perform the procedures described in " General settings " �P160 .
3-4 . REV indicator light and buzzer
3 C
306963
The REV alarm system has the following functions .
� When the engine speed reaches a set speed , the select lever / gear position indicator will illuminate in orange and a buzzer will sound .
� If the engine speed enters the red zone , the select lever / gear position indicator will illuminate in red .
The factory setting ( default setting ) for this function is set as “ OFF ”.
To change the REV indicator light and buzzer settings , perform the procedures described in " Settings Display " �P156
T n d ti
� p
� ti m
Y fo
T T
