178
Light Control Switch NOTE
Even when the operation conditions of the high beam assist function are met , there may be a case in which the high beam assist indicator does not illuminate .
▼ How to temporarily lower the sensitivity of the high beam assist function
The sensitivity of the high beam assist function can be lowered by using the following operations .
1 . After turning the ignition switch to the “ ON ” position , set the light control switch to the “ AUTO ” position and push the signal lever forward ( high beam position ).
2 . After the high beam assist indicator on the combination meter will illuminate , turn the ignition switch to the “ OFF ” position .
3 . Turn the ignition switch to the “ ON ” position and within approximately 15 seconds , press the “ ” ( following distance setting ) switch more than 10 times consecutively .
When the sensitivity of the high beam assist function is lowered , the high beam assist indicator light “ ” on the combination meter display ( color TFT ) will flash .
NOTE
� The sensitivity of the high beam assist function cannot be lowered in the following conditions . - Cruise control or Adaptive Cruise Control indicator is illuminated . - The EyeSight warning indicator ( yellow ) is illuminated � The sensitivity of the high beam assist function returns to normal level the next time the ignition switch is turned to the “ OFF ” position and the engine is restarted . ▼ How to change the headlight mode manually
Change to the low beam : � Set the light control switch to “ ”.
� Pull the lever while the high beam is turning on and release it .
Change to the high beam : Push the lever forward and release it .
At this time , the high beam assist function will turn off , the high beam assist indicator will turn off and the high beam indicator light will turn on .
NOTE
� After manually changing the headlight mode to the high beam , if you turn o th � li th p m p
▼
� n v n fo s d
� d
� b b a a d a c v c a
