BRZ
Manual air conditioning system (if equipped)
A
B
A
C
Air outlet selection dial
To select the air outlets, set the air outlet selection dial
to the desired position.
B
D
C
E
Turn dial to turn on and to select fan speeds.
To adjust the fan speed, turn the fan speed control
dial clockwise (increase) or counterclockwise
(decrease).
F
D
Temperature control dial
To adjust the temperature setting, turn the
temperature control dial clockwise (warm) or
counterclockwise (cool).
E
Fan speed control dial
Rear window and outside rear view
mirror defoggers
Outside air or recirculated air mode
Press
button to select air flow.
ON (recirculated air mode): The indicator light is on.
OFF (outside air mode): The indicator light is off.
F
Press
button to turn on rear window defogger,
outside rear view mirror defogger.
The function will automatically turn off after
approximately 15 min.
Air conditioning ON/OFF button
Press A/C button to select air conditioning ON/OFF.
ON: The indicator light is on.
OFF: The indicator light is off.
MAINTENANCE
To keep your vehicle in proper operating condition and to assure peak performance at all times, the
recommended maintenance service should be performed in accordance with the maintenance schedule.
Refer to the Owner's Manual for information on maintenance items and intervals.
Also, we recommend that you check your vehicle yourself daily for more comfortable use of your vehicle.
When you are going to check your vehicle yourself, please do so in compliance with the Owner’s Manual.
Engine compartment overview
1
3
2
4
1
2
3
4
5
Battery
Engine oil level dipstick
Brake fluid reservoir
Engine oil filler cap
Washer fluid tank
5
15
