Seats 37 |
|||||||||
! Front passenger’ s seat |
S01AQ0602 |
1 Seat position forward / backward control switch To adjust the seat forward or backward, move the control switch forward or backward.
2 Seatback angle( reclining) control switch To adjust the angle of the seatback, move the control switch.
! Power driver’ s seat with synchronized outside mirrors memory function( if equipped)
S01AQ0603
WARNING
. To avoid loss of vehicle control or personal injury, never perform the following operations while
|
driving. – Adjusting the seat
– Selecting a registered seat position
. Before adjusting the seat or selecting a registered seat position, make sure that cargo or the hands and feet of rear seat passengers are clear of the adjusting mechanism.
. The memory adjustment of the seat position is finished. Be sure to confirm that the select lever is in the“ P” position, and the parking brake is applied, when adjusting the seat position. Do not drive until the utilizing of the seat position is complete.
. When any unusual conditions or malfunctions occur during the memory adjustment of the seat position, stop the memory adjustment of the seat position by performing any of the following procedures.
– Operate any of the power seat switches.
– Press the“ SET” button. – Press button“ 1” or“ 2”. – Operate the outside mirror
|
control switch.
Register the seat position with button“ 1” or“ 2” or each of the key fobs.
The following memory positions can be registered.
. Forward / backward position of the seat. Angle of the seatback. Angle of the seat cushion. Height of the seat. Angle of the outside mirrors
. Angle of the outside mirror angle on the passenger’ s side when the reverse tiltdown operates.
NOTE
The seat position can also be retrieved with the Driver Monitoring System user information. To do so, perform user registration in the Driver Monitoring System settings. Refer to“ Driver Monitoring System” FP220.
! Registration of memory position with button“ 1” or“ 2”
S01AQ060301
1. Adjust the seat and outside mirror positions under the following conditions.. The parking brake is applied.. The ignition switch is in the“ ON” position.
|
Seat, seatbelt and SRS airbags |
||||
– CONTINUED – |
