36
Seats
& Power seat( if equipped)
S01AQ06
! Driver’ s seat
S01AQ0601 backward. During forward / backward adjustment of the seat, you cannot adjust the seat cushion angle or seat cushion height.
2 Seat cushion angle control switch To adjust the seat cushion angle, pull up or push down the front end of the control switch.
3 Seat height control switch To adjust the seat height, pull up or push down the rear end of the control switch.
4 Seatback angle( reclining) control switch To adjust the angle of the seatback, move the control switch.
5 Lumbar support control switch( if equipped) To increase lower back support, push the front side of the switch. To decrease lower back support, push the rear side of the switch. To adjust the lumbar support height, push the upper or lower side of the switch.
! Thigh extension( driver’ s seat – if equipped)
S01AQ0604
CAUTION
When the thigh extension is pulled out to its fullest, do not put weight on the top of it. Doing so could break the part.
The seat front length can be adjusted.
Pull up the lever“ 1” to adjust the length and release the lever to lock it.
1 Seat position forward / backward control switch To adjust the seat forward or backward, move the control switch forward or
