384
BSD / RCTA
& BSD / RCTA warning indicator
S07BM04
! System malfunction
S07BM0403
1 BSD / RCTA malfunction message 2 At first, this message will appear 3 Then this message will appear 4 BSD / RCTA warning indicator
This display appears when a malfunction occurs in the system. Contact a SUBARU dealer and have the system inspected.
& To turn on / off the BSD / RCTA
S07BM09
BSD / RCTA OFF indicator
To turn the BSD / RCTA system on and off, operate the center information display. Refer to“ Car settings” FP213.
When the BSD / RCTA system is turned OFF, the BSD / RCTA OFF indicator on the combination meter display( color LCD) will illuminate.
NOTE
. In the following cases, turn off the BSD / RCTA system. The system may not operate properly due to blocked radar waves. – When towing a load – When a bicycle carrier or other item is fitted to the rear of the vehicle
– When using a chassis dynamometer or free roller device, etc.
– When running the engine and making the wheels rotate while lifting up the vehicle
. If the ignition switch is turned to the“ OFF” position, the last known status of the system is maintained. For example, if the ignition switch is turned to the“ OFF” position with the BSD / RCTA deactivated, the BSD / RCTA remains deactivated the next time the ignition switch is turned to the“ ON” position.
& Certification for the BSD / RCTA
S07BM06
! The U. S. and other FCC compliant countries
S07BM0601
FCC ID: OAYSRR3A CAUTION
FCC WARNING
Changes or modifications not expressly approved by the party responsible for compliance could void the user’ s authority to operate the equipment.
