– When the vehicle driving two lanes away is driving on the near side of its lane from your vehicle
& BSD / RCTA OFF indicator
S07BM08
! System temporary stops
S07BM0801
|
stop condition and the indicator will disappear. If the indicator remains displayed for a prolonged time, have the system inspected at a SUBARU dealer.
! System temporary stops due to reduced radar sensitivity
S07BM0802
|
||||
|
. The BSD / RCTA approach indicator light may illuminate when driving close to solid objects on the road or road side( such as guardrails, tunnels or sidewalls).
. The BSD / RCTA approach indicator light may flash when turning at an intersection in urban areas or a multilane intersection.
. The BSD / RCTA approach indicator light may flash and the warning buzzer may sound if a building or a wall exists in the reversing direction.
. In the following cases, the system may detect a vehicle driving two lanes away from your vehicle. – When you are driving on the near side of its lane from the corresponding vehicle
|
1 BSD / RCTA temporary stop message 2 BSD / RCTA OFF indicator
This display appears when the system is used under the following conditions.
. Extremely high or low temperatures
. When abnormal voltage exists for the vehicle battery
. When the radar sensor is significantly misaligned
Once the above conditions are corrected, the system will recover from the temporary
|
1 BSD / RCTA temporary stop message due to reduced radar sensitivity
2 BSD / RCTA OFF indicator
This display appears when the detectability of the radar sensors is reduced. Once the condition is corrected, the system will recover from the temporary stop condition and the indicator will disappear. If the indicator remains displayed for a prolonged time, have the system inspected at a SUBARU dealer.
|
Starting and operating |
||
– CONTINUED – |
