316
Cargo tie-down hooks
& To install the cover housing
S06AK05
6-14. Cargo tie-down hooks
S06AM
1 Cargo cover inner housing 2 Cargo cover outer housing 3 Cargo cover button
1. Hold the cover inner housing and outer housing. Press the cover housing button and lengthen the cover housing.
2. Shorten the cover housing.
3. Insert both ends of the cover housing into the recesses of the retainers.
NOTE
Store the window-side seatbelt in the holder before using the cover housing.
The cargo area is equipped with several tie-down hooks so that cargo can be secured with a cargo net or ropes.
When using the tie-down hooks, turn them down out of the storing recesses.
CAUTION
The cargo tie-down hooks are designed only for securing light cargo. Never try to secure cargo that exceeds the capacity of the hooks. The maximum load capacity is 22 lbs( 10 kg) per hook.
