! Using Two-Way Communication
S03AP110809
|
||||||||
|
Press any of the left, center or right buttons to display the main menu. Select HomeLink menu using the left button.
Select“ STATUS” using the center button.
NOTE
The main menu cannot be displayed on the display while the select lever is in a position other than the“ P” position.
|
1 Status Indicators
Recall and display( at any time) the last recorded garage door status message communicated to HomeLink. HomeLink will display the last recorded status for 5 seconds.
|
1 Garage Door Opener CLOSING( Blinking Orange)
2 Garage Door Opener CLOSED( Solid Green)
3 Garage Door Opener OPENING( Blinking Orange)
4 Garage Door Opener OPENED( Solid Green)
If two-way communication programming is successful, HomeLink will display the status of your garage door opener with arrow indicators.
|
