Mirrors 263 |
|||
|
the motor-head unit( see the device’ s manual to identify this button). The name and color of the button may vary by manufacturer.
NOTE
A ladder and / or second person may simplify the following steps.
11. Firmly press and release the“ Learn”,“ Smart”, or“ Program” button. You now have 30 seconds in which to complete step 12.
12. Return to the vehicle and press the HomeLink left button.
13. Firmly press the HomeLink left button 3 times. At this point, your device should operate when the HomeLink button is pressed and released.
14.“ Program Success”: If the programmed HomeLink button works, select“ Yes” and programming is completed.
In the event that there are still programming difficulties or questions, additional HomeLink information and programming videos can be found at www. HomeLink. com / Subaru and www. youtube. com / HomeLinkGentex. For Genie and Sommer garage door openers, please go directly to the HomeLink website
|
.
! Gate Operator / Canadian Programming
S03AP110803
Canadian radio-frequency laws require transmitter remote signals to“ time-out”( or quit) after several seconds of transmission, which may not be long enough for HomeLink to pick up the signal during programming. Similar to this Canadian law, some U. S. gate operators are designed to“ time-out” in the same manner. The indicator LED on the hand-held remote will go off when the device times out, indicating that it has finished transmitting.
If you live in Canada or you are having difficulties programming a gate operator or garage door opener by using the programming procedures, replace“ Programming a New HomeLink Button” step 3 with the following:
While the HomeLink indicator light is flashing orange, press and release(“ cycle”) your device’ s hand-held remote every two seconds until the HomeLink indicator light changes from orange to green. You may now release the hand-held remote button.
|
NOTE
If programming a garage door opener or gate operator, it is advised to unplug the device during the“ cycling” process to prevent possible overheating.
Proceed with“ Programming a New HomeLink Button” step 4 to complete.
! Using HomeLink
S03AP110804
To operate, simply press and release the programmed HomeLink button. Activation will now occur for the trained device( i. e. garage door opener, gate operator, security system, entry door lock, home / office lighting, etc.). For convenience, the handheld remote of the device may also be used at any time.
! Erasing HomeLink Buttons
S03AP110805
1. Press any of the left, center or right buttons to select the main menu. Select HomeLink menu using the left switch.
2. Select“ SET UP” using the right button.
3. Select“ Continue” using the HomeLink left button.
4. Select the“ Trash can icon” using the HomeLink left button.
|
Instruments and controls |
– CONTINUED – |
