Mirrors 249 |
|||
|
1 Status Indicators
8. If status indicator arrows appear next to the indicator light, please refer to“ Garage Door Two-Way Communication” FP250.
In the event that there are still programming difficulties or questions, additional HomeLink information and programming videos can be found at www. HomeLink. com and www. youtube. com / HomeLinkGentex. For Genie and Sommer garage door openers please go directly to the HomeLink website.
|
! Gate Operator / Canadian Programming
S03AP070410
Canadian radio-frequency laws require transmitter remote signals to“ time-out”( or quit) after several seconds of transmission, which may not be long enough for HomeLink to pick up the signal during programming. Similar to this Canadian law, some U. S. gate operators are designed to“ time-out” in the same manner. The indicator LED on the hand-held remote will go off when the device times out, indicating that it has finished transmitting.
If you live in Canada or you are having difficulties programming a gate operator or garage door opener by using the programming procedures, replace“ Programming a New HomeLink Button” step 3 with the following:
While the HomeLink indicator light is flashing orange, press and release(“ cycle”) your device’ s hand-held remote every two seconds until the HomeLink indicator light changes from orange to green. You may now release the hand-held remote button.
NOTE
If programming a garage door opener or gate operator, it is advised to unplug
|
the device during the“ cycling” process to prevent possible overheating.
Proceed with“ Programming a New HomeLink Button” step 4 to complete.
! Using HomeLink
S03AP070411
To operate, simply press and release the programmed HomeLink button. Activation will now occur for the trained device( i. e. garage door opener, gate operator, security system, entry door lock, home / office lighting, etc.). For convenience, the handheld remote of the device may also be used at any time.
! Erasing HomeLink Buttons
S03AP070412
To erase programming from the three buttons( individual buttons cannot be erased but can be“ reprogrammed” as outlined below), follow the step noted:
Press and hold the two outer HomeLink buttons for at least 10 seconds. The LED indicator will change from continuously lit to rapidly flashing. Release both buttons. Do not hold for longer than 20 seconds. HomeLink is now ready to be programmed at any time beginning with“ Programming a New HomeLink Button” step 1.
|
Instruments and controls |
– CONTINUED – |
