Warning and indicator lights 191 |
|||||||||||
|
NOTE
. The outside temperature indicator shows the temperature in the area around the sensor. However, the temperature may not be indicated correctly or the update may be delayed in the following conditions. – While parking or driving at low speeds
– When the outside temperature changes suddenly( example: when going in and out of an underground parking area or when passing through a tunnel)
– When starting the engine after being parked for a certain period of time
. The icy road surface warning screen should be treated only as a guide. Be sure to check the condition of the road surface before driving.
. Once the icy road surface warning screen appears, it will not disappear unless the outside temperature has increased to 418F( 58C) or higher.
|
& Driver Monitoring System operation indicator light( green)( if equipped)
S03AEA4
This indicator illuminates when the Driver Monitoring System is activated. Refer to“ Driver Monitoring System operation indicator light( green)” FP406.
|
& Driver Monitoring System warning light( yellow)( if equipped)
S03AEB6
This warning light illuminates if the Driver Monitoring System malfunctions. Have your vehicle inspected at a SUBARU dealer as soon as possible. Refer to“ Driver Monitoring System warning light( yellow)” FP406.
|
& Driver Monitoring System OFF indicator light( if equipped) S03AEA5
This indicator illuminates when“ Driver Monitoring System” is touched to deactivate Driver Monitoring System. Refer to“ Driver Monitoring System OFF indicator light” FP406.
|
& Driver Monitoring System temporary stop indicator light( if equipped)
S03AEA6
This indicator illuminates when the Driver Monitoring System is temporarily stopped. Refer to“ Driver Monitoring System temporary stop indicator light” FP406.
NOTE
The Driver Monitoring System stops temporarily in the following circumstances.
. The temperature of the Driver Monitoring System unit is high.
|
& One-touch Interior Illumination indicator
S03AEB5
This indicator light illuminates when the One-touch Interior Illumination function is activated. Refer to“ One-touch Interior Illumination function” FP302.
& Sonar Audible Alarm OFF indicator
S03AE93
This indicator illuminates when the Sonar Audible Alarm is turned OFF. For the setting procedure, refer to“ Car settings” FP213.
|
Instruments and controls |
