190
Warning and indicator lights
& X-MODE indicator
S03AE68
X-MODE indicator( models with 1 mode) 1 X-MODE indicator
X-MODE indicator( models with 2 modes) 1 DEEP SNOW / MUD mode indicator 2 SNOW / DIRT mode indicator
This indicator appears while X-MODE is activated. It will disappear when X-MODE is deactivated. Refer to“ To activate / deactivate X-MODE” FP365.
& Hill descent control indicator
S03AE69
This indicator appears while the hill descent control function is in standby. It will flash while the hill descent control function is operating. It will disappear when the hill descent control function is not available. Refer to“ Hill descent control function” FP367.
& BSD / RCTA warning indicator
S03AE80
This warning indicator appears when the BSD / RCTA is malfunctioning. In this case the BSD / RCTA warning indicator will be shown on the combination meter display. When this indicator appears, have your vehicle inspected by your SUBARU dealer as soon as possible.
& BSD / RCTA OFF indicator
S03AE86
This indicator appears on the combination meter display( color LCD) when“ Rear Vehicle Detection( BSD / RCTA)” is touched to deactivate the BSD / RCTA or when the
BSD / RCTA is suspended temporarily. In this case the BSD / RCTA OFF indicator will be shown on the combination meter display. For details, refer to“ BSD / RCTA” FP377.
& RAB warning indicator
S03AE91
This indicator illuminates if the Reverse Automatic Braking( RAB) system malfunctions. Refer to“ Reverse Automatic Braking( RAB) system” FP386.
& RAB OFF indicator
S03AE92
This indicator illuminates when the Reverse Automatic Braking( RAB) system is turned off, or when the Reverse Automatic Braking( RAB) system is suspended temporarily. Refer to“ Reverse Automatic Braking( RAB) system” FP386.
& Icy road surface warning indicator
S03AE82
When the outside temperature is 378F( 38C) or less, the icy road surface warning will illuminate to inform the driver that the road surface may be frozen.
