148
Windows
“ Initialization of power window( windows with off delay function)” FP148.
! Anti-entrapment function( windows with off delay function)
S02AH0703
While closing the window automatically, if the window senses a substantial enough object trapped between the window and the window frame, it automatically moves down slightly and stops.
If a foreign object is caught while window is opening automatically, the window will stop.
CAUTION
. Never attempt to test the power window operation using body parts.
. If an object is caught just before the window fully closes, the system may not operate properly.
NOTE
. If a window detects an impact similar to that caused by trapping an object( for example, when the vehicle encounters a deep pothole), the antientrapment function may operate.
. You cannot close the window for a few seconds after the anti-entrapment function operates.
! Off delay function
S02AH0705
The windows can be operated for approximately 40 seconds even after the ignition switch is turned to the“ ACC” or“ OFF” position. If a front door is opened within 40 seconds, the off delay function is canceled.
! Locking the passengers’ windows
S02AH0704
1 Lock 2 Unlock
The lock switch is in the lock position, the rear windows cannot be operated by the driver’ s side switches. The passenger’ s side switches and the rear seat side switches are not operational either.
When the indicator on the window switches does not illuminate, the window switch cannot be operated.
& Initialization of power window( windows with off delay function)
S02AH06
If the one-touch auto up and down function or off delay function does not operate properly, operate each window according to the following procedure in order to initialize the power window system.
1. Close the door.
2. Turn the ignition switch to the“ ON” position.
3. Open the window completely and then press and hold down the power window switch for approximately 1 second.
4. Close the window completely and then pull and hold the power window switch for approximately 1 second.
