Windows 147
! Operating the window
S02AH0702
Keys and doors
Passenger’ s side power window switches
Each passenger’ s window can be controlled by the power window switch located on the door.
These switches illuminate when activated.
With one-touch auto up and down feature 1 Automatically close * 2 Close 3 Open 4 Automatically open *
*: To stop the window halfway, operate the switch to the opposite side.
Without one-touch auto up and down feature
1 Close 2 Open
NOTE
Avoid the following.
. Continuously operating a switch in the same direction after the window is fully closed or fully opened.
. Continuously operating three or more switches all at once in the same direction after the windows are fully closed or fully opened.
Either of the operations described above may cause the power window breaker to operate making it impossible to open or close the window. Be sure to initialize the power windows. Refer to
– CONTINUED –
