Surround View Monitor 323 |
|||||||
|
monitor switch .
NOTE
. If you turn off the Surround View Monitor or use it to operate another function , the next time the image is displayed , the previously displayed screen will be shown .
. When “ Rear Camera Delay Control ” is on , the rear-view image will be displayed on the center information display for a certain period of time after the select lever is shifted from the “ R ” position to another position ( other than the “ P ” position ). To turn the function on and off , refer to “ General settings ” FP210 .
! Checking the front
S06BJ0103
When the view monitor switch is pressed while the select lever is in the “ N ” or “ D ” position , the front view is displayed .
|
1 Original screen 2 Top view screen
3 Left-side view screen / Right-side view screen / Front-top view screen
4 Front view screen / Front-top view screen : Press the view monitor switch . : Touch the view icon .
|
NOTE
If you turn off the Surround View Monitor or use it to operate another function , the next time the image is displayed , the previously displayed screen will be shown .
|
& How to cancel Surround View Monitor
S06BJ02
There are several ways to cancel Surround View Monitor .
! Manual cancellation
S06BJ0201
The Surround View Monitor will be canceled by either of the following operations .
. Press the view monitor switch until the original screen is displayed ( when the select lever is other than the “ R ” position ).
. Move the select lever to a position other than the “ R ” position ( when the select lever is in the “ R ” position ).
. Touch ( car settings icon ). . Touch ( HOME ). . Touch ( driver profiles icon ). ! Automatic cancellation
S06BJ0202
If any of the following conditions are met , the Surround View Monitor is canceled automatically .
|
Interior equipment |
|||
– CONTINUED – |
