322
Surround View Monitor
! Checking the rearward
S06BJ0102
When the select lever is move to “ R ”, the image in the rearward direction is displayed . Pressing the view monitor switch or touching the view icon while the image of the rear camera is displayed will switch the screen view .
1 Vehicle icon 2 Vehicle angle icon
When the 3D view is displayed , the display angle switches clockwise from the starting position . When the view returns to the starting position , the display angle stops switching . You can also switch the display angle by touching the vehicle angle icon on the screen .
NOTE
If you turn off the Surround View Monitor or change the screen to operate other functions , the next time the image is displayed , it will be displayed at the previously displayed angle .
1 Original screen 2 Rear view screen / Top view screen / Reverse Automatic Braking ( RAB ) screen
3 Rear view screen / Reverse Automatic Braking ( RAB ) screen
4 Top view screen : Shift the select lever . : Touch the view icon or press the view
