Warning and indicator lights 181 |
|||||||||||||
|
mately 2 seconds after the engine has started .
. The warning light illuminates right after the engine is started but turns off immediately , remaining off .
. The warning light remains illuminated after the engine has been started , but it turns off while driving .
. The warning light illuminates during driving , but it turns off immediately and remains off .
When driving with an insufficient battery voltage , such as when the engine is jump started , the ABS warning light may illuminate . This is due to the low battery voltage and does not indicate a malfunction . When the battery becomes fully charged , the light will turn off .
|
& Brake system warning light
S03AE10
This light illuminates with the parking brake applied while the ignition switch is in the “ ON ” position . It turns off when the parking brake is fully released .
WARNING
|
. Driving with the brake system warning light on is dangerous . This indicates your brake system may not be working properly . If |
the light remains illuminated , have the brakes inspected by a SUBARU dealer immediately .
. If at all in doubt about whether the brakes are operating properly , do not drive the vehicle . Have your vehicle towed to the nearest SUBARU dealer for repair .
The brake system warning light has the following functions .
! Brake fluid level warning
S03AE1002
This light illuminates when the brake fluid level has dropped to near the “ MIN ” level of the brake fluid reservoir with the ignition switch in the “ ON ” position and with the parking brake fully released .
|
If the brake system warning light should illuminate while driving ( with the parking brake fully released and with the ignition switch positioned in “ ON ”), it could be an indication of leaking of brake fluid or worn brake pads . If this occurs , immediately stop the vehicle at the nearest safe location and check the brake fluid level . If the fluid level is below the “ MIN ” mark in the reservoir , do not drive the vehicle . Have the vehicle towed to the nearest SUBARU dealer for repair . |
! Electronic Brake Force Distribution ( EBD ) system warning
S03AE1003
If the warning light remains on even though the parking brake is released , the brake fluid level may be low or there could be a problem with the EBD system . Park the vehicle in a safe place immediately and contact a SUBARU dealer .
! Electronic brake booster warning
S03AE1009
The brake system warning light illuminates when the electronic brake booster is malfunctioning . If the warning light illuminates , promptly park in a safe location as soon as possible and contact your SUBARU dealer .
|
& Electronic parking brake indicator light |
S03AE85
! Parking brake indicator
S03AE8501
The light illuminates with the parking brake applied while the ignition switch is in the “ ON ” position . It turns off when the parking brake is fully released .
! Electronic parking brake system warning
S03AE8502
WARNING
. When you release the electronic parking brake while the engine is
|
