180
Warning and indicator lights
Otherwise an accident involving serious vehicle damage and serious personal injury could occur .
If this light still illuminates while driving after adjusting the tire pressure , a tire may have significant damage and a fast leak that causes the tire to lose air rapidly . If you have a flat tire , replace it with a spare tire as soon as possible .
When a spare tire is mounted or a wheel rim is replaced without the original pressure sensor / transmitter being transferred , the Low tire pressure warning light will illuminate steadily after blinking for approximately one minute . This indicates the TPMS is unable to monitor all four road wheels . Contact your SUBARU dealer as soon as possible for tire and sensor replacement and / or system resetting .
If the light illuminates steadily after blinking for approximately one minute , promptly contact a SUBARU dealer to have the system inspected .
CAUTION
The tire pressure monitoring system is NOT a substitute for manually checking tire pressure . The tire pressure should be checked periodically ( at least monthly ) using a tire gauge . After any change to tire pressure ( s ), the tire pressure monitoring system will not re-check tire inflation pressures until the vehicle is first driven more than 20 mph ( 32 km / h ). After adjusting the tire pressures , increase the vehicle speed to at least 20 mph ( 32 km / h ) to start the TPMS re-checking of the tire inflation pressures . If the tire pressures are now above the severe low pressure threshold , the low tire pressure warning light should turn off a few minutes later . Therefore , be sure to install the specified size for the front and rear tires .
& ABS warning light CAUTION
S03AE09
. If any of the following conditions occur , we recommend that you have the ABS repaired at the first available opportunity by your SUBARU dealer .
– The warning light does not illuminate when the ignition switch is turned to the “ ON ” position .
– The warning light illuminates when the ignition switch is turned to the “ ON ” position , but it does not turn off even after the vehicle is started .
– The warning light illuminates during driving .
. When the warning light is on ( and the brake system warning light is off ), the ABS function shuts down . However , the conventional brake system continues to operate normally .
The ABS warning light , Vehicle Dynamics Control warning light , and brake system warning light illuminate simultaneously if the EBD system malfunctions . For further details of the EBD system malfunction warning , refer to “ Electronic Brake Force Distribution ( EBD ) system warning ” FP181 .
NOTE
If the warning light behavior is as described in the following conditions , the ABS may be considered normal .
. The warning light illuminates when the ignition switch is turned to the “ ON ” position and turns off approxi-
