Stanley Spare Part E-Book | Page 62

STEL721
1500W 254mm Mitre Saw
59
Item No. Product Number Qty Per Product Description Type Other Info Markets
Guide Price
(Rp)
10 5140015-10 1 SHIELD 329,800
11 5140015-11 1 SHIELD 29,800
12 5140015-12 1 RING 11,000
13 5140015-13 1 SCREW 11,000
14 5140015-14 1 SCREW 11,000
15 5140015-15 1 TUBE EXTRACTION 12,500
16 5140015-16 1 PIN 11,000
17 5140015-17 1 STOP PLATE 15,700
18 5140015-18 1 SPRING 42,300
19 5140015-19 1 BOLT 11,000
20 5140015-20 1 NUT 11,000
21 5140015-21 1 SCREW 11,000
22 5140015-22 1 BOLT 11,000
23 5140015-23 1 OUTER FLANGE 25,000
24 5140069-57 1 INNER FLANGE 25,000
25 5140015-25 1 SCREW 11,000
26 5140015-26 1 COVER 23,500
27 5140069-58 1 SPINDLE 45,400
28 5140069-59 1 GEAR 115,700
29 5140069-60 1 FLANGE 25,000
30 5140015-30 1 SCREW 11,000
31 5140015-31 1 RING 11,000
32 5140069-61 1 KEY 11,000
33 5140015-33 1 BEARING 36,000
34 5170007-06 1 BEARING,BALL 31,300
35 5140015-35 1 SPRING 11,000
36 5140015-36 1 BUTTON 15,700
37 5140015-37 1 SPINDLE LOCK 15,700
39 5170007-07 1 GEAR CASE SA 159,400
40 5140015-40 1 O RING 11,000
41 5140015-41 1 BEARING 36,000
42 5140012-94 1 ARMATURE 573,500
43 5140015-43 1 BEARING 346,900
44 5140015-44 1 SLEEVE 11,000
45 5140015-45 1 BAFFLE FAN 15,700
46 5140015-46 1 SCREW 11,000
47 5140012-96 1 STATOR 453,200
48 5170007-25 1 FIELD CASE 150,000
49 5140015-49 1 SCREW 11,000
50 5140015-50 1 BRUSH 43,800
51 5140015-51 1 BRUSH HOLDER 15,700
52 5140015-52 1 SPRING 11,000
53 5140015-53 1 SCREW 11,000
54 5140015-54 1 SCREW 11,000
55 5170007-26 1 CAP 40,700
56 5170007-29 1 RATING LABEL B1 11,000
57 5140069-64 1 SCREW 11,000
58 5140069-65 1 SCREW 11,000
59 5170007-30 1 HANDLE & COVER 89,200
60 5170005-81 1 CORDSET B1 96,900
61 5140047-30 1 CORD PROTECTOR 14,200
62 5140015-62 1 PROTECTOR 11,000
63 5140069-67 1 CORD CLAMP 11,000
64 5140047-31 1 SCREW 11,000
65 5140047-32 1 SCREW 12,500
66 5170007-33 1 HANDLE 61,000
67 5170007-34 1 CLAMSHELL 87,500
69 5140047-35 1 SWITCH 50,000
70 5140047-36 1 TRIGGER 14,200
71 5140015-71 1 SCREW 11,000
72 5140015-72 1 SHIELD 11,000
73 5140015-73 1 SHIELD 125,000
74 5140015-74 1 SPRING TORSION 12,500
75 5140015-75 1 SCREW 11,000
76 5140015-76 1 PLATE 21,900
77 5140015-77 1 BOLT 11,000
78 5140015-78 1 SHIELD 23,500
79 5140015-79 1 SCREW 11,000
80 5140015-80 1 WASHER 11,000
81 5170005-82 1 KNOB 12,500
82 5140015-82 1 BAFFLE 128,200
83 5140015-83 1 NUT 11,000
84 5140015-84 1 PIN 11,000
85 5140015-85 1 LOCKING PIN 15,700
86 5170005-83 1 CAP 11,000
