[ Ball Bearing ]
[ Ball Bearing ]
Stainless steel ball bearings offer a critical balance between mechanical strength and corrosion resistance. Photo: Dreamstime.
AISI 440C contains high carbon and chromium levels, enabling it to be heat treated to very high hardness levels, typically up to ~ 60 HRC under conventional through-hardening conditions. This makes it particularly suitable for bearing races and rolling elements requiring high loadcarrying capacity and resistance to rolling contact fatigue. While 440C provides lower corrosion resistance than austenitic grades such as
304 or 316, it significantly outperforms standard bearing steel( AISI 52100) in corrosive environments. Its excellent grindability and ability to achieve a fine, polished surface further support its use in precision bearing applications.
Manufacturing 440C bearing steel The production of AISI 440C bearing steel begins with controlled melting in an electric arc furnace( EAF), followed
by secondary refining in ladle refining furnaces( LRF) and vacuum degassing( VD) to achieve tight chemical composition control and low inclusion content. In modern production routes, the steel is typically continuously cast into billets or blooms. Continuous casting offers improved yield, productivity, and consistency compared to ingot casting. Process parameters such as casting speed, temperature control, electromagnetic stirring, and secondary cooling are carefully optimised to minimise segregation, surface cracking, and centreline porosity. These measures are critical for ensuring uniform microstructure and reliable performance after subsequent heat treatment.
Major ball bearing components The functionality of rolling-element bearings relies on the interaction of four primary components:
• Inner ring( race): Mounted on the rotating shaft, providing a hardened raceway for the rolling elements
• Outer ring( race): Installed in the stationary housing, forming the opposing raceway
• Rolling elements: Balls or rollers that carry the load and enable rolling motion
