TRACTION DEVICES
TORQUE WORM LSD
The Torque Worm is a torque biasing 6 pinion gear type limited slip unit. This is a preloaded unit allowing for a faster reacting unit. Unlike our competitors that only use 3 or 4 pinion gears. The use of 6 pinion gears means the stress on gears is spread over a greater surface area, reducing the load on all internal components.
The internal components are made from EN36 Material as used in racing such as V8 SUPERCAR. The outer cases made from 8620 Chrome-Nickel-Moly steel and the case hardened for long life and improved strength. The Torque Work unit is available in 28 and 31 spline counts. A 35 Spline unit is under development at this time.
TDS1301 _ TDS1302 _ TDS1303 _ TDS1304 _ TDS1305 _ TDS1306 _ TDS1307 _ TDS1308 _ TDS1309 _
28 Spline Ford 9” Torque Worm LSD 31 Spline Ford 9” Torque Worm LSD 35 Spline Ford 9” Torque Worm LSD 28 Spline 80 Series BORG / W Torque Worm LSD 31 Spline 80 Series BORG / W Torque Worm LSD 30 Spline M86 DANA Torque Worm LSD 32 Spline ZF Torque Worm LSD 32 Spline AAM GM 8.6 Torque Worm LSD 31 Spline Ford 8.8 IRS Torque Worm LSD
LOCKER
The purpose of the Locker is to maximize traction by delivering 100 precent of the torque and power to both drive wheels. They are engineered to keep both wheels in a constant drive mode and have the ability to automatically allow wheel speed differentiation when required to ease cornering at low speeds.
TDS1351 _ TDS1352 _ TDS1353 _
28 Spline Ford 9” Locker 31 Spline Ford 9” Locker 35 Spline Ford 9” Locker www. TRACTIONDRIVESYSTEMS. com
