CFT RIZZARDI
Ausstellung innovativer Werkzeugwechselsysteme, darunter die Chainless Technology und Hochleistungslösungen für CNC-Bearbeitungszentren.
mit unterschiedlichen Kegeln handhaben. Die mit 4 Schrauben an den Paletten befestigten Werkzeughalterbuchsen können leicht ausgetauscht werden, z. B. bei Bruch durch Kollision oder beimÄndern des Kegeltyps, auch beim Endverbraucher.
PATENTIERTER RADFÖRMIGER WERKZEUG- WECHSLER VOM TYP CTR 40- CTR 50 PF
Dieser Werkzeugwechsler erfüllt die Anforderungen von Herstellern, die hochproduktive Maschinen realisieren, wie horizontale Bearbeitungszentren und Transfermaschinen, da er die Nebenzeiten der Werkzeugmaschine optimiert und die Werkzeugwechselzeiten reduziert. Bei Standard-Werkzeugwechslern muss ein großes Werkzeug so positioniert werden, dass die benachbarten Plätze frei bleiben. Daher muss es „ mit festem Platz” gehandhabt
➥ not anchored to a chain, as in conventional magazines, but are mounted on separate wheeled pallets sliding on guides and moved by pushing. Therefore, it is possible to overturn or transfer the tool pocket selected. This system also allows the installation of the tool magazine in small spaces or even in orthogonal layouts, and the drive requires less power due to the absence of the chain.
LESS MAINTENANCE From the viewpoint of maintenance, the absence of chains brings considerable advantages related to the increased lightness of the system and less wear over time. As a result, maintenance is simplified because the adjustments necessary to offset the elongation of the chain are reduced to a minimum and replacements in the event of breakage are facilitated, as there is no need to replace the entire chain.
SHUTTLE TOOL CHANGER CTNE 50 Tool changer with magazine suitable for installation on table and floor type boring-milling machines, gantry machines, etc. The drives are exclusively electric and hydropneumatic and can even handle tools with different tapers using the same maga-
34 SPECIALE EMO
