Das Ziel von Trevisan ist es seit jeher, Lösungen anzubieten, die den Bedürfnissen eines jeden Kunden gerecht werden. Das Unternehmen hat nun eine Universalmaschine entwickelt, die in ihrer Art einzigartig ist: das neue Bearbeitungszentrum DS900 Universal.
WERKSTÜCKE MIT HOHEM MEHRWERT
Die mit einem flüssigkeitsgekühlten 68-kW- Direktantrieb ausgerüstete Maschine kann die Bearbeitungsköpfe wechseln und so von einer schweren Fräsmaschine mit einem maximalen Drehmoment von 7400 Nm bei niedrigen Drehzahlen zu einem Hochgeschwindigkeitsbearbeitungszentrum mit einer 42-kW-Elektrospindel zu 400 Nm und einer maximalen Drehzahl von 6000 U / min umgerüstet werden. Die neue DS900 Universal deckt nicht nur Fräs- und Bohrarbeiten ab, sondern auf ihr können auch Bearbeitungsköpfe mit CNCgesteuerten Drehvorrichtungen von Trevisan installiert werden, die Durchmesser von bis zu 1200 mm drehen können. Auch die Spin-
Der Unternehmenssitz von Trevisan Macchine Utensili in Sovizzo( Vicenza)
FULLY INTEGRATED TURNING AND MILLING
The goal of Trevisan Macchine
Utensili has always been to offer solutions that meet the needs of each single customer. The company has created a one-of-a-kind universal machine: the new DS900 Universal machining centre.
The machining centres by Trevisan Macchine Utensili are used in a variety of industrial sectors, from oil and gas to the production of electric motor housings, hydroelectric turbine blades, and wind turbine components.
VALUE-ADDED PARTS Equipped with a 68 kW liquid-cooled direct drive, the DS900 Universal can change front heads so as to allow the transition from a heavy-duty milling machine with a maximum torque of 7,400 Nm at low speeds to a high-speed machining centre using a 42 kW, 400 Nm electrospindle with a maximum speed of 6,000 rpm. In addition to milling / drilling, it can also feature front heads equipped with CNC-controlled Trevisan turning units for diameters up to 1,200 mm. The heavy-duty milling spindle also incorporates a U-axis to accommodate small turning heads and special tools. The machining centre can be also equipped with double-joint universal heads with 360 positions or 18,000 positions. All front heads are loaded automatically from a dedicated magazine installed on the X-axis of the machining centre. The magazine can slide into the machine, allowing for head changing without having to unload the pallet currently processed. The
