GRINDING TECHNOLOGY
Die auf der EMO 2023 ausgestellte
Konfiguration umfasst zwei Elektrospindeln für CBN-Schleifscheiben für Außenschleifarbeiten und eine Elektrospindel für Innenschleifarbeiten
Die Produktionsstätte in Cassine , Italien , in der die Maschinen von Morara und Tacchella von hochspezialisierten Technikern entworfen , montiert und getestet werden
nehmens fortsetzen , das wirklich bedeutende technologische Entwicklungen aufzuweisen hat , vor allem wenn man bedenkt , dass es weltweit nicht mehr als ein Dutzend Hersteller gibt , die in der Lage sind , Systeme dieses Niveaus herzustellen .“ Das Modell E-Proflex GL , das auf der EMO zu sehen sein wird , verfügt über eine Konfiguration mit zwei externen Spindeln für Außenschleifarbeiten und einer Spindel für Innenschleifarbeiten , konventionelle und CBN-Schleifscheiben , einen Werkstückhaltekopf mit direktem Torque-
Motor , der 100 kg überhängend tragen kann , einen hydraulischen Reitstock , der die Bearbeitung sowohl ausladend als auch zwischen den Spitzen ermöglicht , wiederum im Sinne einer hohen Produktivität bei der Außenbearbeitung , sowie eine mit Torque-Motor ausgestattete B- Achse , die bis auf Zehntausendstel Grad beliebig positionierbar ist : Dieser letzte Aspekt ist sehr wichtig , da er die Entnahme der Fertigteile aus der Maschine ohne ein weiteres Versetzen ermöglicht . Die von Grinding Technology entwickelten und patentierten Gleitsysteme der
Führungen sind in der Lage , die wärmebedingte Ausdehnung der Maschine besser zu bewältigen . Die Maschine ist mit einer numerischen Steuerung von Siemens und einem 21,5-Zoll- Full-Touch-Display sowie einer betriebsintern entwickelten Bedienerschnittstelle namens T . O . P . ( Tool Operator Package ) ausgestattet , d . h . einer speziellen interaktiven Software , die den Bediener auf einfache Weise und unter Einhaltung der Sicherheitsvorschriften Schritt für Schritt durch die gesamte Steuerung der Maschine führt . „ Unser Slogan Erfahrung im Dienst der Innovation findet seinen höchsten Ausdruck in der E-Proflex GL , die aus einem altbewährten Produkt wie der Baureihe Proflex hervorgegangen ist . Diese ist zwar zuverlässig und gut auf dem Markt etabliert , wurde aber dank der beträchtlichen und ab 2019 in Forschung und Entwicklung getätigten Investitionen viel leistungsfähiger und entspricht voll
➥ cams , crankshafts or eccentric motions in general . “ For our entire
family provided with granite bed / linear motor , which also includes the Proflex GL and the Morara MD ID , the choice of incorporating this type of bed is also a productive one , since natural granite can be fashioned in a single piece , thus making the machine design flexible . Along with the linear motor , the E-Proflex GL is suitable for an application field – that of cams – allowing practically zero play at the inversion point and thus making the production process very performing “ said Alessio Zemo , Sales Director of Grinding Technology . “ With the creation of this machine we are aiming at strengthening the significant growth of our company , which is making major technological advancements , considering that there are no more than a dozen manufacturers who can build systems of this level throughout the world .” At EMO , the E-Proflex GL will be exhibited in a configuration with two spindles for external grinding and one for internal grinding , with both conventional and CBN grinding wheels , a workpiece holder head with a direct torque motor that supports 100 kg cantilevered , a hydraulic tailstock for processing the workpiece , in cantilevered mode or between the centres , sticking to the subject of high productivity for external jobs , as well as a B axis equipped with a torque motor that can be freely swivelled with a resolution of 0.0001 degrees : the latter feature is very important because it allows the operator to remove the finished parts from the machine , without the need for further positioning . The sliding systems of the guideways , designed and patented by Grinding Technology , are able to better manage the thermal expansion of the machine . The E-Proflex GL is also equipped with a Siemens numerical control and a 21.5 “ full-touch display combined with a user interface developed in Cassine , called T . O . P . ( Tool Operator Package ), or a dedicated interactive software
