und längere Lebensdauer der Werkzeuge . Die Bearbeitungseinheit für das thermische Schneiden ist mit einem geraden Plasmakopf oder Bevel ausgestattet , welcher präzise Schnitte und hohe Qualität ermöglicht . Das TIPO G25LGE- Modell kann mit einem Hauptschneidebrenner und mit bis zu zwei Hilfsschneidebrennern ausgerüstet werden . Die neue TIPO G25LGE ist ein “ Digital Native ” mit allerneuestem HMI Polaris aus der FICEP- Entwicklung , welcher die Handhabung der Bearbeitungsprogramme und die Bedienerfreundlichkeit verbessert . Polaris wird in den kommenden Jahren an allen FICEP-Stahlbauanlagen eingesetzt .
VIELE VERSCHIEDENE BEARBEITUNGSARTEN , EINE LÖSUNG
Die neue FICEP CNC-Anlage XBLADE für Bohr- , Fräs- und Schneidbearbeitungen für Stahlprofile ist dank ihres modularen Aufbaus in der Lage , Stahlträger verschiedener Größen zu bearbeiten , und zwar bei Querschnitten von bis zu 305X305 mm an drei Seiten , bei 450x450 mm an einer Seite und dies bei verschiedenen Längen . Sie führt komplexe Bohr- , Gewindeschneid- , Gewindebohr- , Fräs- und Schneidbearbeitungen aus und ist eine universelle Maschine , die sich auch für Bearbeitungen von Leichtmetallprofilen eignet . Das innovative Merkmal dieser Maschine besteht darin , dass sie Drei-Achs-Bearbeitungen auch an schrägen Flächen in zwei verschiedenen Richtungen ausführt . Der aus zwei Drehgelenken bestehende 5-Achsen-Kopf positioniert das Werkzeug an jedwedem Punkt des Bearbeitungsbereiches . Hinzu kommt , dass durch die Einführung des Scheibenblatts die Palette an Bearbeitungen , die ohne manuelle Eingriffe ausgeführt werden können , erweitert wird : durch die Integration des Schneidblatts mit dem 5-Achsen-Kopf kann das Werkstück ringsum an fünf Seiten bearbeitet werden . Das Werkzeugmagazin der Maschine verfügt über acht Positionen für normale Werkzeuge , zwei Positionen für große Werkzeuge und eine Position für das 560-mm-Schneidblatt . Das Maschinendesign ist sehr kompakt und der Schaltschrank , die Klimatisierung sowie das Kühlsystem für die Spindelflüssigkeit sind in die Maschine integriert . Mithilfe der FICEP-Software Steel Project kann das Nesting del Profils programmiert und optimiert werden , hingegen mithilfe der Software CAM , die das Programm ISO erzeugt , wird der Arbeitszyklus mit Leichtigkeit gestartet .
Halle 13 Stand C52
head and up to two auxiliary oxy-fuel units . The new TIPO G25LGE features a native Polaris HMI , the latest interface model developed by FICEP which improves part program management and usability . Polaris will be implemented soon on all FICEP structural steel fabrication machines .
MANY TASKS , A SINGLE SOLUTION FICEP ’ s new XBLADE CNC line for drilling , milling and sawing steel profiles is able to machine structural steel beams into different sizes with cross-sections up to 305x305 mm on three sides , or up to 450x450 mm on one side , and variable lengths thanks to its modular configuration . It performs complex drilling , tapping , milling and disc sawing operations and is a “ universal ” machine which also lends itself to the processing of light alloy profiles . The innovative feature of this machine is the ability to carry out three-axis machining even on inclined planes , in two different directions . The 5-axis head , consisting of two rotating wrists , places the tool virtually anywhere in the working range . In addition , the introduction of the disc blade expands the range of processes that can be carried out without manual operations : the integration of the disc blade with the 5-axis head makes it possible to machine the workpiece on 5 sides . The tool magazine has 8 positions for standard tools , two positions for large tools and one position accommodating the 560 mm disc blade . The machine features a very compact design and the electric cabinet is integrated on board and so the conditioning system and the spindle fluid cooling system . The FICEP Steel Project software makes it possible to programme and optimise profile nesting while the CAM software generates the ISO program . As a result , the work cycle is launched with great ease .
