CFT RIZZARDI
anstatt sie untereinander mit einer Kette oder einem Riemen zu verbinden . Durch die Chainless Technology tritt im Lauf der Zeit weniger Verschleiß auf und es fallen weniger Nachstellarbeiten an , die sonst aufgrund der bei Ketten typisch auftretenden Verlängerungsphänome durchzuführen sind . Aufgrund des geringeren bewegten Gewichts und des Gleitens auf Rollen ist diese Lösung auch mit einer deutlichen Reduzierung der Motorleistung verbunden . Sollten die Werkzeughalterbuchsen brechen oder beschädigt werden ,
erfolgt ihr Austausch relativ problemlos , da nicht die gesamte Kette ausgebaut werden muss , um eine einzelne Einheit auszuwechseln . Das System mit Chainless Technology ist vor allem bei Anwendungen sehr gefragt , bei denen eine höhere Aufnahmekapazität des Werkzeugmagazins im Vergleich zu Standardausführungen gefragt ist , insbesondere bei hochproduktiven Werkzeugmaschinen . Der aktuelle Trend bei CNC-Werkzeugmaschinen geht in der Tat in die Richtung , die Maschine mit allen Werkzeugen auszustatten , die für die Bearbeitung eines
➥ large tools with a maximum weight of 40 kg , configurable up to 300 tools according to the customer ’ s specifications . CFT Rizzardi also manufactures special tool changers tailored to the customer ’ s needs .
AUTOMATIC TOOL CHANGER The flagship product of CFT Rizzardi is the CTA .. HS tool magazine , patented back and available in versions for various applications . Particularly appreciated for use in small spaces and in customised projects . Thanks to its characteristics of flexibility and versatility , the CTA .. HS automatic tool changer can be applied easily to machine tools of various types , such as horizontal and vertical machining centres , milling machines , transfer machines , vertical lathes and special machines . This magazine model is available in different types and shapes according to the customer ’ s needs , exploiting the space available on the machine as much as possible .
CHAINLESS TECHNOLOGY FOR INNOVATIVE TOOL CHANGERS Covered by an international patent , the Chainless Technology system is different from the traditional tool magazines currently available on the market because it does not need to use chains or belts . This innovative technology conveys the tools in the magazine fastened to pallets , independently of each other , pushing them instead of moving them by means of a chain or a belt . The Chainless Technology makes it possible to reduce wear over time by eliminating or minimising the adjustments typically required due to the slackening of the chains . Thanks to the lower weight to be handled and the sliding motion on rollers , this solution also involves a significant reduction in motor power . Maintenance in case of breakage or damage to the tool pockets is simplified , since it is not necessary to disassemble the entire chain for replacing a single unit . The Chainless Technology system is proving particularly successful in applications where greater capacity is required with respect to
