SERVOPRO NOx
SAFE AREA
CHEMILUMINESCENCE DETECTOR ANALYZER FOR KEY EMISSIONS APPLICATIONS INVOLVING ULTRA-LOW NO ,
NO2 AND NOx
Utilizing Chemiluminescence detection technology to measure NO or NO / NO2 / NOx concentrations in industrial gas and vehicle emission applications , the versatile SERVOPRO NOx can be calibrated for four measurement ranges starting from ultra-low to high ppm and is easy to install and operate .
FEATURES AND BENEFITS
High-dynamic-range NOx emissions monitoring solution with a fast response
Non-depleting light-based measurement and electronic flow control keeps costs low
Heated version available for wet to dry conversion option
Mobile Source emissions standard EPA 1065 / 1066 and LD Euro 6 , HD Euro V1 compliant
APPLICATIONS
Continuous Emissions Monitoring Systems Scrubber efficiency Turbine / generator feedback control SCR / SNCR feedback control
GAS MEASURES APPLICATION
NITRIC OXIDE
NITROGEN DIOXIDE
NITROGEN OXIDES
CHEMILUMINESCENCE
TRACE PPM
SENSING TECHNOLOGY
PROCESS CONTROL
QUALITY
EMISSIONS
SERVOPRO HFID
SAFE AREA
HIGH-PERFORMANCE FAST ANALYSIS USING HEATED FID
Using a highly sensitive heated Flame Ionization Detector ( HFID ) for measuring volatile hydrocarbon concentrations in industrial or vehicle emission applications , the HFID utilizes an internally heated oven set to 190 ° C ( 374 ° F ), to maintain the sample gas above its dew point , for optimum performance in THC analysis . Can be equipped with a non-methane cutter for additional methane ( CH 4
) and non-methane hydrocarbon ( NMHC ) reporting .
FEATURES AND BENEFITS
Four user-definable measurement ranges , reconfigurable in the field
High-accuracy , gas-selective FID technology for maximized uptime
Heated oven for maximum stability and " hot / wet " sampling
EPA Method 25A compliant
EPA 1065 / 1066 and LD Euro 6 , HD Euro V1 compliant
APPLICATIONS
Continuous Emissions Monitoring Systems VOC abatement Scrubber efficiency Compliance monitoring and testing
GAS MEASURES APPLICATION
TOTAL HYDROCARBONS
METHANE
NON-METHANE HYDROCARBONS
FLAME IONIZATION DETECTOR
TRACE PPM
SENSING TECHNOLOGY
PROCESS CONTROL
QUALITY
EMISSIONS
GAS DETECTION OxyDetect
SERVOMEX
NON-DEPLETING PARAMAGNETIC
O2 MONITOR DESIGNED FOR LIFE SAFETY APPLICATIONS
Oxygen depletion monitor designed for safe area or hazardous area environments , utilizing superior performance of non-depleting Hummingbird Paramagnetic O2 sensing technology .
FEATURES AND BENEFITS
IP54 ( indoor use only ) The most reliable O2 detector on the market
No more false readings or false alarms caused by depleting cell technologies
Configurable alarm relays and mA output available as standard
Modbus digital communications option available
SIL 2 hardware compliant
APPLICATIONS
Pharmaceutical plants Helium production and storage Semiconductor facilities Laboratories and universities
GAS MEASURES APPLICATION
OXYGEN PERCENT SAFETY
SENSING TECHNOLOGY
P107
