SPATIAL DEPTH CUES
In an elevation drawing, we try to establish three pictorial zones: the
foreground space between thesection cut andthe facade of t he
building; the middleground t hat t he building itself occupies; and the
background of sky, landscape, or structures beyondthebuilding.
