sINGle Gas mONItOr
SPECIFICATIONS
By wearing the Tango™ TX1, workers will be the safest
single gas monitor users in the world. A 3-year runtime
and patent pending DualSense ™ Technology increases
worker safety, regardless of bump test frequency, while
reducing overall costs. Let the Tango show you why two
is better than one.
PART NO.
DESCRIPTION
INstrumeNt cONfIGuratIONs
TX1-1
TX1-2
TX1-4
TX1-5
Tango TX1, CO
Tango TX1, H 2 S
Tango TX1, NO 2
Tango TX1, SO 2
accessOrIes
18109249-ABC DS2 Docking Station™ for Tango™ TX1
Ordering Information
B = number of iGas ® Readers: 0 – none
1 = 1 iGas Reader
2 = 2 iGas Readers
3 = 3 iGas Readers
C = Power cord Option (0 – US, 1 – UK, 2 – EU,
3 – AUS, 4 – ITA, 5 – DEN, 6 – SWZ)
17154367
Replacement battery
17155161
Replacement sensor, Carbon Monoxide, pack of two
17155164 Replacement sensor, Hydrogen Sulfide, pack of two
17155162 Replacement sensor, Nitrogen Dioxide, pack of two
17155163 Replacement sensor, Sulfur Dioxide, pack of two
18109171 Soft nylon case, Black
18109239
18109218
18109230
18109238
17120908
17154915-0
17154915-1
17154916
17154917
17154918
17154919
17154920 Soft nylon case, Orange
Dust barrier kit, 5 pack
Water barrier kit, 5 pack
CalCup and tubing kit
Belt clip
AlarmAmp™, Black
AlarmAmp™, Safety Orange
Black nameplate
Green nameplate
Yellow nameplate
Blue nameplate
White nameplate
INSTRUMENT WARRANTY:
Three year warranty which does not include battery, sensors and filters.
CO and H 2 S sensors are warranted for 3 years from the initial purchase date.
All other sensors are warranted for 2 years from the initial purchase date.
DISPLAY:
Segment liquid crystal display (LCD)
KEYPAD:
Two buttons
CASE MATERIALS:
Case top: Polycarbonate with a protective rubber overmold
Case bottom: Conductive polycarbonate
ALARMS:
Three strobe-emitting visual alarm LEDs (two red; one blue);100 decibel
(dB) audible alarm at a distance of 10 cm (3.94"); Vibration alarm
DIMENSIONS:
99 x 51 x 35 mm (3.9" x 2.0" x 1.4")
WEIGhT:
126.0 g (4.4 oz.)
TEMPERATURE RANGE:
-40°C to +50°C (-40°F to +122°F)†
hUMIDITY RANGE:
15%-95% Non-condensing (continuous)
SENSORS:
CO, H 2 S, NO 2 , SO 2 - Electrochemical sensor technology
SENSOR MEASURING RANGES:
Carbon Monoxide (CO):
0 to 1,000 ppm in 1 ppm increments
0.0 to 200.0 ppm in 0.1 ppm increments
Hydrogen Sulfide (H 2 S):
0.0 to 150.0 ppm in 0.1 ppm increments
Nitrogen Dioxide (NO 2 ):
0.0 to 150.0 ppm in 0.1 ppm increments
Sulfur Dioxide (SO 2 ):
BATTERY PACK:
3.6 V Primary lithium-thionyl chloride (Li-SOCl2); 1.5AH, 2/3AA; replaceable;
nonrechargeable; always on; 3 year run time depending on operating conditions
DATALOGGING:
3 months at 10-second intervals
EVENTLOGGING:
60 alarm events
CERTIFICATIONS
INGRESS PROTECTION:
IP66; IP67
-40°C TO +50°C (-40°F TO +122°F)
ATEX
Ex ia I Ma, Ex ia IIC T4 Ga, Equipment Group and Category: I M1
and II 1G
IECEx
Ex ia I Ma, Ex ia IIC T4 Ga
UL (C-US) Class I, Groups A, B, C, and D; Class II, Groups E, F, and G; T4;
Exia, Class I, Zone 0, AEx ia IIC T4
-20°C TO +50°C (-4°F TO +122°F)
CSA
Ex ia IIC; Class I, Groups A B C D; T4
China
Ex Ex ia IIC T4 Ga
INMETRO Ex ia IIC T4 Ga
PENDING:
MSHA
Permissible Gas Monitor
KOSHA
Ex ia IIC T4 Ga
China MA Safety Certificate of Approval for Mining Products
These specifications are based on performance averages and may vary by instrument.
* The Tango is warranted to be free from defects in material and workmanship
under normal and proper use and service for 3 years from the initial purchase date.
† Operating temperatures above 50 °C (122 °F) may cause reduced instrument accuracy.
Operating temperatures below -20 °C (-4 °F) may cause reduced instrument accuracy and affect
display and alarm performance.
alarmamp™
For higher-noise environments, the
Tango’s alarm volume, typically 100dB
at 10 cm, can be increased nearly 10dB
with the addition of the optional patent
pending AlarmAmp™. The Tango’s alarm
is louder than that of any other single gas
instrument on the market.
