OrderING INfOrmatION
SMALL INSTALLATION SCENARIO
sINGle-lOcatION
cOmPaNy
Illustrates one DS2 instal-
lation on a stand-alone
Ethernet, with 2 IDSs in a
cluster sharing 2
cylinders of calibration gas.
PART NO.
DESCRIPTION
18106724-ABC DS2 Instrument Docking Station (IDS) for MX6 iBrid™
18108630-ABC DS2 Instrument Docking Station (IDS) for Ventis™ MX4
18109249-ABC DS2 Instrument Docking Station (IDS) for Tango™ TX1
18106302-ABC DS2 Instrument Docking Station (IDS) for GasBadge ®
Pro
-ABC
13
B = Quantity of iGas ® Reader:
0 = None
1 = 1 iGas ® Reader
Instrument data is available
at the local level.
2 = 2 iGas ® Readers
3 = 3 iGas ® Readers
C = Power Cord: 0 = US, 1 = UK, 2 = EU,
3 = AUS, 4 = ITA, 5 = DEN, 6 = SWZ
LARGE INSTALLATION SCENARIO
18106543-5 MX6 iBrid/DS2 Laptop Turnkey System+
18106543-8 Ventis MX4/DS2 Laptop Turnkey System+
18109261 Tango/DS2 Laptop Turnkey System+
18106543-4 GasBadge Pro/DS2 Laptop Turnkey System+
17113978 DS2 PC with Windows ® Server OS++
17153596-EUR-FR DS2 Server, European, French Version++
17153596-EUR-EN DS2 Server, European, English Version++
MULTI-LOCATION COMPANY
Illustrates multiple IDS cluster installations at multiple sites all
tied together on a common company Ethernet, sharing a
common database. Each cluster of IDSs share calibration gas.
Instrument data can be accessed at the plant level as well as by
the corporate safety office.
18105684 iGas ® Reader
18105841 Demand Flow Regulator w/ iGas ® Pressure Switch
(for 58L, 103L and 34L aluminum cylinders)
18105866 Demand Flow Regulator, 600 CGA w/ iGas Pressure
Switch (for 34L steel cylinders)
18105833 Demand Flow Regulator, 590 CGA w/ iGas Pressure
Switch (for 552L cylinders)
18105858 Demand Flow Regulator, 330 CGA w/ iGas Pressure
Switch (for 650L cylinders)
18102509 Demand Flow Regulator, 5/8 UNF (for 58L, 103L and
34L aluminum cylinders)
18103564 Demand Flow Regulator, 600 CGA (for 34L steel
cylinders)
18103549 Demand Flow Regulator, 590 CGA (for 552L cylinders)
18103556 Demand Flow Regulator, 330 CGA (for 650L cylinders)
18105924 5-Port Gas Regulator Manifold
17113929 4-Port Ethernet Router, Cable/DSL
17113937 4-Port Ethernet Wireless Router
17113887 Ethernet Cable, 5’ (Cat5E network cable)
17113895 Ethernet Cable, 10’ (Cat5E network cable)
17113903 Ethernet Cable, 25’ (Cat5E network cable)
17113911 Ethernet Crossover Cable, 5’ (Cat5E network cable)
17113945 5-Port Ethernet Hub
17113952 16-Port Ethernet Hub
17113960 24-Port Ethernet Hub
+ Includes (1) DS2, Computer (installed software: Windows ® 7, DSS and DSSAC), monitor,
keyboard, mouse, 5-port Ethernet hub and cables.
++ Includes keyboard and mouse. Monitor and DS2 not included.
Look for this Symbol on All
Compatible Instrument Pages
