Automates instrument calibration,
record-keeping, diagnostics and
recharging
Stand-alone Instrument Docking
Stations (IDS)
Link up to 100 IDSs
Dock hundreds of
instruments
Multilingual display
One centralized
database
SPECIFICATIONS
COMPATIBLE MONITORS SUPPORTED:
MX6 iBrid™, Ventis™ MX4, GasBadge ® Pro, Tango™ TX1
CASE:
Impact-resistant composite with radio frequency interference (RFI) protection
DIMENSIONS:
24.8 cm x 16.3 cm x 22.9 cm (9.75" h x 6.40" w x 9.00" d)
INPUT:
115/230 VAC, 50/60 Hz. 12 VDC
OPERATING TEMPERATURE:
0ºC to +50ºC (32º F to +122ºF)
COMMUNICATION:
10bT Ethernet support, RJ-45 category 5 connection
DISPLAY:
128 x 64 Dot Matrix LCD – Multilingual modes allow selections in English,
Spanish, French and German languages
U.S. Patent #6,442,639
International Patent #WO0182063
for managing your gas monitors wherever you use them.
Ethernet connectivity enables you to link up to 100 stand-
alone Instrument Docking Stations (IDSs) from anywhere in
your facility and relay the data back to one central database
for total instrument management. A graphical user interface
tool allows an administrator to view operations on each
Docking Station from a network computer, making it easy
to track instruments, print reports, set events and change
parameters for any location. The DS2 gives you all of the
battery recharging, and instrument diagnostics for your
monitors to limit your liabilities and safety hazards.
Each individual IDS features a multilingual display, three
status LEDs, a keypad and an audible alarm to provide
important instrument details at a single glance. The DS2,
which can be easily grouped into ‘clusters’ of up to 5 units to
share calibration gas, also offers optional iGas ® capability to
automatically identify calibration gas cylinder concentrations,
lot numbers, and expiration dates on the system. Whether
PUMP FLOW RATE:
500 ml/minute @ 80" H 2 O
GAS INPUTS:
3 separate inputs on each IDS. Ability to share up to 14 discrete gases for
calibration when IDSs are clustered together.
DS2 COMPUTER REqUIREMENTS (MIN):
For 1-8 IDS units: Dedicated Pentium III, 800 MHz, 256 MB RAM,
4GB available disk space, Windows ® 2000 Professional, Windows ® XP
Professional operating system, one Cat5E Ethernet network adapter, fixed
IP address
For 9-100 IDS units: Dedicated Pentium III, 800 MHz,
256 MB RAM, 4GB available disk space, Windows ®
2000 Standard Server, Windows ® 2003 Server
operating system, one Cat5E Ethernet network
adapter, fixed IP address
