30
SPECIALTY BASE CABINETS
Base EZ and Lazy Susan Clearance
Note: If either side of Lazy Susan is exposed, then
order AP2435 side panel to cover 3” gap
BLSXX
BEZXX
AP2435
Base EZ Reach Corner Cabinet (BEZ)
•
•
•
•
•
•
Requires 36” x 36” space
Fits through 32” door opening
165 degree side hinges and knuckle hinges in center
Includes 1 full depth, adjustable shelf
Not available with soft close hinge
Must specify Left or Right (L/R)
WIDTH
INCHES
33
MODEL
NUMBER
BEZ33L/R
36
BEZ36L/R
WIDTH
INCHES
33
MODEL
NUMBER
BLS33
36
BLS36L/R
WIDTH
INCHES
30
MODEL
NUMBER
BOK30
21”
BASE CABINETS
Base Lazy Susan Corner Cabinet (BLS)
•
•
•
•
•
•
•
•
21”
Requires 36” x 36” space
Fits through 32” door opening
Includes 2 spinning steel wire baskets
33” uses 24” revolving tray
36” uses 32” revolving tray
3” gap at back
Not available with soft close hinge
Must specify Left or Right (L/R)
Metal
Oven Base Frame Kit (BOK)
Fillers
• Requires field fabrication
• Kit includes bottom panel, rails for floor kits and
3” solid fillers to be ripped in field
• Oven frame should mount flush to front of
adjacent side panels
• Allows a 30” oven to fit into a 30” opening
• Oven sits on bottom panel
Top View
24”
Oven Base Cabinet (BOV)
Frame
Cutout Height
min 19 7/8”
max 26 7/8”
24”
See Chart
• Complete cabinet,
oven sits on bottom panel
• Oven frame is flush with
adjacent doors
WIDTH
INCHES
30
33
36
MODEL
NUMBER
BOV30
BOV33
BOV36
WIDTH
CUT OUT DIMENSIONS
MIN.
MAX.
OPENING
OPENING
21 7/8”
26 7/8”
24 7/8”
29 7/8”
27 7/8”
32 7/8”
