Product Technical Guides : US-EN Direct Fastening - Volume 1 Edition 22 | Page 166

Table 9 — Diaphragm stiffness ( G ') and flexibility factor ( F ) equation variable values
Deck gauge ( inches )
Configuration
22 ( 0.0295 )
20 ( 0.0358 )
18 ( 0.0474 )
16 ( 0.0598 )
Deck type 2
B or BI
Min . deck tensile ( yield ) strength , ksi
45 or 92 ( 33 or 80 )
Frame fastener
X-HSN 24 or S-RT5 + M9
X-ENP-19
S-MD 12-24x1-5 / 8 M HWH5
Sidelap
S f
, in ./ kip
S f
, in ./ kip
S f
, in ./ kip
S f
, in ./ kip
connector 1
S s
, in ./ kip
S s
, in ./ kip
S s
, in ./ kip
S s
, in ./ kip
Hilti SLC or Hilti # 10 HWH Screw
Hilti SLC or Hilti # 10 HWH Screw
Hilti SLC or Hilti # 10 HWH Screw
1 Reference Table 3 and Section 3.5.6 for more information on the proper selection of Hilti Sidelap Connectors ( SLC ). 2 Reference ICC-ES ESR-2776 for Verco PLB deck and VSC2 sidelap connectors .
0.0073
0.0066
0.0057
0.0051
0.0175
0.0159
0.0138
0.0123
0.0044
0.0040
0.0034
0.0030
0.0175
0.0159
0.0138
0.0123
0.0076
0.0069
0.0060
0.0053
0.0175
0.0159
0.0138
0.0123
Table 10 — Minimum recommended sidelap connector spacing ( Inches center-to-center ) for X-HSN 24 and X-ENP-19 powder-actuated fasteners with B-Deck or BI-Deck type
Frame fastener base material thickness , in .
X-HSN 24 1 / 8 ≤ t f
< 3 / 16
X-HSN 24 3 / 16 ≤ t f
≤ 3 / 8
X-ENP-19 t f
≥ 1 / 4
Deck gauge
Frame fastener pattern 36 / 3 36 / 4 36 / 5 36 / 7 36 / 9 2 36 / 11 2 SLC 1 # 10 SLC 1 # 10 SLC 1 # 10 SLC 1 # 10 SLC 1 # 10 SLC 1 # 10
22
20
18
–
–
≥ 12
≥ 6
≥ 12
≥ 6
≥ 6
≥ 3
≥ 6
≥ 3
≥ 6
≥ 3
16
–
–
–
–
–
–
–
–
–
–
22
20
18
16
≥ 12
–
≥ 3
–
≥ 6
≥ 3
≥ 6
≥ 3
≥ 3
≥ 3
≥ 3
≥ 3
≥ 3
≥ 3
22
20
18
≥ 6
≥ 3
≥ 6
≥ 3
≥ 6
≥ 3
≥ 3
≥ 3
≥ 3
≥ 3
≥ 3
≥ 3
16
1 Hilti SLC spacings less than those tabulated may be used . The tabulated spacing should be used in the calculation of diaphragm shear strength when using the P , P and c values from nf ns
Table 8 . Alternatively , only when the SLC spacings are less than those tabulated , the P , P and c values found in Table 8 can be replaced by the following values . nf ns
X-HSN 24 – All deck types , strengths and base steel thicknesses listed in Table 8 22 Gauge ( 0.0295 in .) - P = 1489 lb , P = 716 lb , c = 1 . 000 nf ns
20 Gauge ( 0.0358 in .) - P = 1795 lb , P = 869 lb , c = 1 . 000 nf ns
18 Gauge ( 0.0474 in .) - P = 2348 lb , P = 1151 lb , c = 1 . 000 nf ns
16 Gauge ( 0.0598 in .) - P = 2924 lb , P = 1452 lb , c = 1 . 000 nf ns
2 For 36 / 9 and 36 / 11 patterns , when wind ( or seismic ) diaphragm shear capacities exceed the values shown below , the fastening pattern must be increased at the building perimeter , chords , collectors or other shear transfer elements to two fasteners per rib ( i . e . 36 / 14 pattern ). The wind ( or seismic ) diaphragm shear capacity must not be greater than that determined from the 36 / 9 and 36 / 11 patterns , as applicable .
X-HSN 24 with steel support framing thicknesses 1 / 8 " ≤ t f < 3 / 16 "
ASD wind ( seismic )
LRFD wind ( seismic )
LSD wind ( seismic )
22 Gauge ( 0.0295 in .) -
1275 plf ( 1200 plf )
2100 plf ( 1950 plf )
28.5 N / mm ( 26.3 N / mm )
20 Gauge ( 0.0358 in .) -
1600 plf ( 1500 plf )
2625 plf ( 2450 plf )
35.8 N / mm ( 32.8 N / mm )
18 Gauge ( 0.0474 in .) -
1825 plf ( 1700 plf )
3000 plf ( 2675 plf )
39.0 N / mm ( 37.2 N / mm )
X-HSN 24 with steel support framing thicknesses 3 / 16 " ≤ t f ≤ 3 / 8 "
ASD wind ( seismic )
LRFD wind ( seismic )
LSD wind ( seismic )
22 Gauge ( 0.0295 in .) -
1400 plf ( 1300 plf )
2300 plf ( 2125 plf )
31.0 N / mm ( 28.8 N / mm )
20 Gauge ( 0.0358 in .) -
1700 plf ( 1600 plf )
2800 plf ( 2600 plf )
37.9 N / mm ( 35.0 N / mm )
18 Gauge ( 0.0474 in .) -
2250 plf ( 2100 plf )
3700 plf ( 3425 plf )
50.0 N / mm ( 46.3 N / mm )
16 Gauge ( 0.0598 in .) -
2775 plf ( 2600 plf )
4550 plf ( 4225 plf )
61.7 N / mm ( 56.9 N / mm )
