Anchor Fastening Technical Guide , Edition 22
Table 102 — Hilti HIT-HY 200 A / R V3 allowable tension and shear values for threaded rods based on steel strength 1 , 2 , 3
Anchor diameter in .
3 / 8
1 / 2
5 / 8
3 / 4
ISO 898 class 5.8
ASTM A36
Tension lb ( kN ) Shear lb ( kN )
ASTM A307
ASTM A193 B7
ASTM F593 CW ( 316 / 304 ) HIT- ( Z ( -R )
ISO 898 class 5.8
ASTM A36
ASTM A307
ASTM A193 B7
ASTM F593 CW ( 316 / 304 ) HIT- ( Z ( -R )
2,640 2,115 2,185 4,555 3,645 3,430 1,360 1,090 1,125 2,345 1,875 1,770 ( 11.7 ) ( 9.4 ) ( 9.7 ) ( 20.3 ) ( 16.2 ) ( 15.3 ) ( 6.0 ) ( 4.8 ) ( 5.0 ) ( 10.4 ) ( 8.3 ) ( 7.9 ) 4,700 3,755 3,885 8,100 6,480 6,100 2,420 1,935 2,000 4,170 3,335 3,145 ( 20.9 ) ( 16.7 ) ( 17.3 ) ( 36.0 ) ( 28.8 ) ( 27.1 ) ( 10.8 ) ( 8.6 ) ( 8.9 ) ( 18.5 ) ( 14.8 ) ( 14.0 ) 7,340 5,870 6,075 12,655 10,125 9,535 3,780 3,025 3,130 6,520 5,215 4,915 ( 32.6 ) ( 26.1 ) ( 27.0 ) ( 56.3 ) ( 45.0 ) ( 42.4 ) ( 16.8 ) ( 13.5 ) ( 13.9 ) ( 29.0 ) ( 23.2 ) ( 21.9 ) 10,570 8,455 8,750 18,225 12,390 13,735 5,445 4,355 4,505 9,390 6,385 7,075 ( 47.0 ) ( 37.6 ) ( 38.9 ) ( 81.1 ) ( 55.1 ) ( 61.1 ) ( 24.2 ) ( 19.4 ) ( 20.0 ) ( 41.8 ) ( 28.4 ) ( 31.5 )
3.2.2
Table 103 — Hilti HIT-HIT-HY 200 A / R V3 allowable tension and shear values for reinforcing bars based on steel strength 1 , 2 , 3
Rebar size
# 3
# 4
# 5
# 6
Tension lb ( kN ) Shear lb ( kN ) ASTM A615 , GRADE 60 ASTM A615 , GRADE 60 3,270 1,685 ( 14.5 ) ( 7.5 ) 5,940 3,060 ( 26.4 ) ( 13.6 ) 9,205 4,745 ( 40.9 ) ( 21.1 ) 13,070 6,730 ( 58.1 ) ( 29.9 )
1 Allowable load used in the design must be the lesser of bond values and tabulated steel values . 2 The allowable tension and shear values for threaded rods to resist short term loads , such as wind or seismic , must be calculated in accordance with the appropriate IBC Sections . 3 Allowable steel loads are based on tension and shear stresses equal to 0.33 x Fu and 0.17 x Fu , respectively .
Anchor Fastening Technical Guide Edition 22 | 3.0 ANCHORING SYSTEMS | 3.2.2 HILTI HIT-HY 200 A / R V3 Hilti , Inc . 1-800-879-8000 | en español 1-800-879-5000 | www . hilti . com | Hilti ( Canada ) Corporation | www . hilti . ca | 1-800-363-4458
101
