Systèmes d'ancrage mécanique
3.3.1 Cheville à verrouillage de forme HDA
Perforateurs requis pour poser les chevilles HDA
HDA en acier ordinaire zingué
Cheville
Perforateur Hilti 1
TE 25
(1 re vitesse)
TE 35
TE 40/
40-AVR
TE 56/
56-ATC
TE
60-ATC
TE 70/
70-ATC
TE 75 TE-76/
76-ATC TE
80-ATC
emmanchement
TE-C
TE-Y
HDA-P M10x100/20 ● ● ● ●
HDA-T M10x100/20 ● ● ● ●
HDA-P M12x125/30 ● ● ● ●
HDA-T M12x125/30 ● ● ● ●
HDA-P M12x125/50 ● ● ● ●
HDA-T M12x125/50 ● ● ● ●
HDA-P M16x190/40 ● ● ● ●
HDA-T M16x190/40 ● ● ● ●
HDA-P M16x190/60 ● ● ● ●
HDA-T M16x190/60 ● ● ● ●
HDA-P M20x250/50 ● ● ●
HDA-T M20x250/50 ● ● ●
HDA-P M20x250/100 ● ● ●
HDA-T M20x250/100 ● ● ●
TE 75 TE-76/
76-ATC TE
80-ATC
HDA-R en acier inoxydable
Cheville
Perforateur Hilti 1
TE 25
(1 re vitesse)
TE 35
TE 40/
40-AVR
TE 56/
56-ATC
TE
60-ATC
TE 70/
70-ATC
emmanchement
TE-C
TE-Y
HDA-PR M10x100/20 ● ● ● HDA-TR M10x100/20 ● ● ● ● ●
HDA-PR M12x125/30 ● ● ● ● ●
HDA-TR M12x125/30 ● ● ● ● ●
HDA-PR M12x125/50 ● ● ● ● ●
HDA-TR M12x125/50 ● ● ● ● ●
HDA-PR M16x190/40 ● ● ● ●
HDA-PR M16x190/60 ● ● ● ●
HDA-PR M16x190/60 ● ● ● ●
HDA-TR M16x190/60 ● ● ● ●
TE 70/
70-ATC TE 75 TE-76/
76-ATC TE
80-ATC
HDA-F en acier ordinaire shérardisé (galvanisation à résistance supérieure)
Cheville
Perforateur Hilti 1
TE 25
(1 re vitesse)
TE 35
TE 40/
40-AVR
TE 56/
56-ATC
TE
60-ATC
emmanchement
TE-C
TE-Y
HDA-PFM10x100/20 ● ● ●
HDA-TF M10x100/20 ● ● ●
HDA-PF M12x125/30 ● ● ●
HDA-TF M12x125/30 ● ● ●
HDA-PF M12x125/50 ● ● ●
HDA-TF M12x125/50 ● ● ●
HDA-PF M16x190/40 ● ● ● ●
HDA-TF M16x190/40 ● ● ● ●
HDA-PF M16x190/60 ● ● ● ●
HDA-TF M16x190/60 ● ● ● ●
1 Pour assurer la conformité au code IBC, se reporter à l'ESR-1546 ou communiquer avec le soutien technique de Hilti.
