Tableau 16 — Hilti KH-EZ , KH-EZ P , KH-EZ PM , KH-EZ PL , KH-EZ C et KH-EZ CRC dans le soffite du béton léger non fissuré sur le platelage métallique 1 , 2 , 3 , 4 , 5 , 6
Diamètre de cheville nominal ( po )
1 / 4
3 / 8
1 / 2
5 / 8
3 / 4
Encastrement nominal po ( mm ) ƒ ' c
= 3 000 psi lb ( kN )
Installation dans la cannelure inférieure Installation dans la cannelure supérieure
Tension - фN n Cisaillement - фV n
Tension - фN n Cisaillement - фV n ƒ ' c
= 4 000 psi lb ( kN ) ƒ ' c
= 3 000 psi lb ( kN ) ƒ ' c
= 4 000 psi lb ( kN ) ƒ ' c
= 3 000 psi lb ( kN ) ƒ ' c
= 4 000 psi lb ( kN ) ƒ ' c
= 3 000 psi lb ( kN ) ƒ ' c
= 4 000 psi lb ( kN )
1 5 / 8
545
595
725
725
670
730
725
725
( 41 )
( 2,4 )
( 2,6 )
( 3,2 )
( 3,2 )
( 3,0 )
( 3,2 )
( 3,2 )
( 3,2 )
2 1 / 2
1 220
1 410
1 325
1 325
1 275
1 470
1 960
1 960
( 64 )
( 5,4 )
( 6,3 )
( 5,9 )
( 5,9 )
( 5,7 )
( 6,5 )
( 8,7 )
( 8,7 )
1 5 / 8
845
975
905
905
970
1 120
2 200
2 200
( 41 )
( 3,8 )
( 4,3 )
( 4,0 )
( 4,0 )
( 4,3 )
( 5,0 )
( 9,8 )
( 9,8 )
2 1 / 2
1 455
1 680
905
905
1 900
2 195
3 655
3 655
( 64 )
( 6,5 )
( 7,5 )
( 4,0 )
( 4,0 )
( 8,5 )
( 9,8 )
( 16,3 )
( 16,3 )
3 1 / 4
( 83 )
2 550
( 11,3 )
2 945
( 13,1 )
2 165
( 9,6 )
2 165
( 9,6 )
s . o .
s . o .
s . o .
s . o .
2 1 / 4
850
980
965
965
905
1 045
4 710
4 710
( 57 )
( 3,8 )
( 4,4 )
( 4,3 )
( 4,3 )
( 4,0 )
( 4,6 )
( 21,0 )
( 21,0 )
3
( 76 )
1 990
( 8,9 )
2 300
( 10,2 )
1 750
( 7,8 )
1 750
( 7,8 )
s . o .
s . o .
s . o .
s . o .
4 1 / 4
( 108 )
3 485
( 15,5 )
4 025
( 17,9 )
2 155
( 9,6 )
2 155
( 9,6 )
s . o .
s . o .
s . o .
s . o .
3 1 / 4
( 83 )
2 715
( 12,1 )
3 135
( 13,9 )
2 080
( 9,3 )
2 080
( 9,3 )
s . o .
s . o .
s . o .
s . o .
5
( 127 )
6 170
( 27,4 )
7 125
( 31,7 )
2 515
( 11,2 )
2 515
( 11,2 )
s . o .
s . o .
s . o .
s . o .
4
( 102 )
2 715
( 12,1 )
3 135
( 13,9 )
2 255
( 10,0 )
2 255
( 10,0 )
s . o .
s . o .
s . o .
s . o .
Tableau 17 — Hilti KH-EZ , KH-EZ P , KH-EZ PM , KH-EZ PL , KH-EZ C et KH-EZ CRC dans le soffite du béton léger fissuré sur le platelage en métal 1 , 2 , 3 , 4 , 5 , 6
Diamètre de cheville nominal ( po )
1 / 4
3 / 8
1 / 2
5 / 8
3 / 4
Encastrement nominal po ( mm ) ƒ ' c
= 3 000 psi lb ( kN )
Installation dans la cannelure inférieure Installation dans la cannelure supérieure
Tension - фN n
7
Cisaillement - фV n
8
Tension - фN n
7
Cisaillement - фV n
8 ƒ ' c
= 4 000 psi lb ( kN ) ƒ ' c
= 3 000 psi lb ( kN ) ƒ ' c
= 4 000 psi lb ( kN ) ƒ ' c
= 3 000 psi lb ( kN ) ƒ ' c
= 4 000 psi lb ( kN ) ƒ ' c
= 3 000 psi lb ( kN ) ƒ ' c
= 4 000 psi lb ( kN )
1 5 / 8
280
305
725
725
340
370
725
725
( 41 )
( 1,2 )
( 1,4 )
( 3,2 )
( 3,2 )
( 1,5 )
( 1,6 )
( 3,2 )
( 3,2 )
2 1 / 2
605
700
1 325
1 325
635
735
1 960
1 960
( 64 )
( 2,7 )
( 3,1 )
( 5,9 )
( 5,9 )
( 2,8 )
( 3,3 )
( 8,7 )
( 8,7 )
1 5 / 8
525
605
905
905
770
890
2 200
2 200
( 41 )
( 2,3 )
( 2,7 )
( 4,0 )
( 4,0 )
( 3,4 )
( 4,0 )
( 9,8 )
( 9,8 )
2 1 / 2
1 035
1 195
905
905
1 345
1 555
3 655
3 655
( 64 )
( 4,6 )
( 5,3 )
( 4,0 )
( 4,0 )
( 6,0 )
( 6,9 )
( 16,3 )
( 16,3 )
3 1 / 4
( 83 )
1 805
( 8,0 )
2 085
( 9,3 )
2 165
( 9,6 )
2 165
( 9,6 )
s . o .
s . o .
s . o .
s . o .
2 1 / 4
535
620
965
965
640
740
4 710
4 710
( 57 )
( 2,4 )
( 2,8 )
( 4,3 )
( 4,3 )
( 2,8 )
( 3,3 )
( 21,0 )
( 21,0 )
3
( 76 )
1 255
( 5,6 )
1 450
( 6,4 )
1 750
( 7,8 )
1 750
( 7,8 )
s . o .
s . o .
s . o .
s . o .
4 1 / 4
( 108 )
2 195
( 9,8 )
2 535
( 11,3 )
2 155
( 9,6 )
2 155
( 9,6 )
s . o .
s . o .
s . o .
s . o .
3 1 / 4
( 83 )
1 710
( 7,6 )
1 975
( 8,8 )
2 080
( 9,3 )
2 080
( 9,3 )
s . o .
s . o .
s . o .
s . o .
5
( 127 )
3 885
( 17,3 )
4 485
( 20,0 )
2 515
( 11,2 )
2 515
( 11,2 )
s . o .
s . o .
s . o .
s . o .
4
( 102 )
1 710
( 7,6 )
1 975
( 8,8 )
2 255
( 10,0 )
2 255
( 10,0 )
s . o .
s . o .
s . o .
s . o .
1 Voir PTG Ed . 21 Section 3.1.8 pour convertir la valeur de dureté de la conception en valeur ASD . 2 L ’ interpolation linéaire entre les profondeurs d ’ enrobage et les forces de compression du béton n ’ est pas autorisée . 3 La valeur tabulaire est pour un ancrage par cannelure . L ’ espacement minimum le long de la cannelure est de 3 x h nom
( intégration nominale ).
4 Les valeurs tabulaires sont du béton léger et aucun facteur de réduction supplémentaire n ’ est nécessaire . 5 Aucun facteur de réduction supplémentaire pour l ’ espacement ou la distance des bords ne doit être appliqué . 6 La comparaison avec les valeurs d ’ acier du tableau 4 n ’ est pas requise . Valeurs dans les tableaux 16 et 17 .
7 Les valeurs tabulaires sont uniquement pour les charges statiques . La conception sismique n ’ est pas autorisée pour le béton non fissuré . Pour les charges de tension sismique , multipliez les valeurs tabulaires de béton fissurées en tension seulement par α N seis
= 0,75 . Voir PTG Ed . 21 Section 3.1.8 pour plus de renseignements .
8 Pour les tailles d ’ ancrage suivantes , un facteur supplémentaire de cisaillement sismique doit être appliqué aux valeurs tabulaires de béton fissuré pour les conditions sismiques : 1 / 4 po de diamètre - α v seis à 0,75
3 / 8 po de diamètre - α v seis = 0,60
1 / 2 po de diamètre - α v seis = 0,60
5 / 8 po de diamètre - α v seis = 0,60
3 / 4 po de diamètre - α v seis = 0,70
