PARAMÈTRES D ' INSTALLATION
Tableau 1 – Spécifications de HSL-3-R
Détails Symbole Unités
Diamètre nominal de cheville M8 M10 M12 M16 M20
Diamètre nominal du foret d bit mm 12 15 18 24 28
Épaisseur minimale du béton h min mm 120 140 150 200 250 ( po ) ( 4 3 / 4 ) ( 5 1 / 2 ) ( 5 7 / 8 ) ( 7 7 / 8 ) ( 9 7 / 8 )
Profondeur minimale du trou h o mm 80 90 105 125 155 ( po ) ( 3 1 / 8 ) ( 3 9 / 16 ) ( 4 1 / 8 ) ( 4 15 / 16 ) ( 6 1 / 8 )
Profondeur minimale effective d ' encastrement
Diamètre minimal du trou de la pièce à fixer
Diamètre du trou fraisé dans la pièce HSL-3-SKR
Diamètre de la tête fraisée dans la pièce HSL-3-SKR
Écart cumulatif maximal entre les pièces à fixer et la surface de béton
Épaisseur maximale de la pièce à fixer ( HSL-3-R )
Longueur hors-tout de la cheville ( HSL-3-R )
Épaisseur maximale de la pièce à fixer ( HSL-3-GR )
Longueur hors-tout de la cheville ( HSL-3-GR )
Épaisseur maximale de la pièce à fixer ( HSL-3-SKR )
Longueur hors-tout de la cheville ( HSL-3-SKR )
h ef , min
mm
( po )
60
( 2,36 )
70
( 2,76 )
80
( 3,15 )
100
( 3,94 )
125
( 4,92 )
d h
mm
( po )
14
( 9 / 16 )
17
( 11 / 16 )
20
( 13 / 16 )
26
( 1 )
31
( 1 1 / 4 )
d SK
mm
( po )
22,5
( 7 / 8 )
25,5
( 1 )
32,9
( 1 5 / 16 )
S . O .
S . O .
h SK
mm
( po )
5,8
( 1 / 4 )
6
( 1 / 4 )
8
( 5 / 16 )
S . O .
S . O .
-
mm
( po )
4
( 1 / 8 )
5
( 3 / 16 )
8
( 5 / 16 )
9
( 3 / 8 )
12
( 1 / 2 )
t fix , max
mm
( po )
20
( 3 / 4 )
40
( 1 1 / 2 )
20
( 3 / 4 )
40
( 1 1 / 2 )
25
( 1 )
50
( 2 )
25
( 1 )
50
( 2 )
30
( 1 1 / 8 )
60
( 2 1 / 4 )
l
mm
( po )
98
( 3 7 / 8 )
118
( 4 5 / 8 )
110
( 4 3 / 8 )
130
( 5 1 / 8 )
131
( 5 1 / 8 )
156
( 6 1 / 8 )
153
( 6 )
178
( 7 )
183
( 7 1 / 4 )
213
( 8 3 / 8 )
t fix , max
mm
( po )
20
( 3 / 4 )
100
( 4 )
20
( 3 / 4 )
100
( 4 )
25
( 1 )
100
( 4 )
25
( 1 )
100
( 4 )
30
( 1 1 / 8 )
100
( 4 )
l
mm
( po )
102
( 4 )
182
( 7 1 / 8 )
115
( 4 1 / 2 )
197
( 7 3 / 4 )
139
( 5 1 / 2 )
214
( 8 1 / 2 )
163
( 6 3 / 8 )
238
( 9 3 / 8 )
190
( 7 1 / 2 )
260
( 10 1 / 4 )
t fix , max
mm
( po )
20
( 3 / 4 )
20
( 3 / 4 )
25
( 1 )
S . O .
S . O .
l
mm
( po )
98
( 3 7 / 8 )
110
( 4 3 / 8 )
131
( 5 1 / 8 )
S . O .
S . O .
Couple d ' installation ( HSL-3 )
T inst
Nm
( pi-lb )
25
( 18 )
35
( 26 )
80
( 59 )
120
( 89 )
200
( 148 )
Couple d ' installation ( HSL-3-GR )
T inst
Nm
( pi-lb )
30
( 22 )
50
( 37 )
80
( 59 )
120
( 89 )
200
( 148 )
Couple d ' installation ( HSL-3-SKR )
T inst
Nm
( pi-lb )
18
( 13 )
50
( 37 )
80
( 59 )
S . O .
S . O .
Dimension de clé ( HSL-3-R , HSL-3-GR )
SW
mm
13
17
19
24
30
Dimension de clé Allen ( HSL-3-SKR ) SW mm 5 6 8 S . O . S . O .
