3.0 MODULAR SUPPORT SYSTEM 3.1.2 MT BEAM AND COLUMN LOAD TABLES
Modular Support Systems Technical Guide, Edition 1
Table 35- MT-20 Maximum Factored Beam Loads: X-axis Bending 1, 2, 3, 4, 5
Span in( cm)
Max Factored Uniform Load lbs( N)
Defl. At Max Uniform Load in( cm)
Uniform Loading at Deflection
Span / 180 lbs( N)
Span / 240 lbs( N)
Span / 360 lbs( N)
12
1,680
0.03
1,680
1,680
1,680
( 30.5)
( 7,470)
( 0.07)
( 7,470)
( 7,470)
( 7,470)
24
840
0.12
840
725
480
( 61.0)
( 3,735)
( 0.29)
( 3,735)
( 3,220)
( 2,135)
36
560
0.26
430
320
215
( 91.4)
( 2,490)
( 0.66)
( 1,910)
( 1,420)
( 955)
48
420
0.46
240
180
120
( 121.9)
( 1,865)
( 1.18)
( 1,065)
( 800)
( 530)
60
335
0.72
150
115
75
( 152.4)
( 1,490)
( 1.84)
( 665)
( 510)
( 330)
72
280
1.04
105
80
50
( 182.9)
( 1,245)
( 2.65)
( 465)
( 355)
( 220)
Table 36- MT-20 Maximum Factored Beam Loads: Y-axis Bending 1, 2, 3, 4, 5
Span in( cm)
Max Factored Uniform Load lbs( N)
Defl. At Max Uniform Load in( cm)
Uniform Loading at Deflection
Span / 180 lbs( N)
Span / 240 lbs( N)
Span / 360 lbs( N)
12
2,500
0.02
2,500
2,500
2,500
( 30.5)
( 11,120)
( 0.05)
( 11,120)
( 11,120)
( 11,120)
24
1,250
0.08
1,250
1,250
980
( 61.0)
( 5,560)
( 0.22)
( 5,560)
( 5,560)
( 4,355)
36
830
0.19
830
655
435
( 91.4)
( 3,690)
( 0.48)
( 3,690)
( 2,910)
( 1,930)
48
625
0.34
490
365
245
( 121.9)
( 2,780)
( 0.86)
( 2,175)
( 1,620)
( 1,085)
60
500
0.53
315
235
155
( 152.4)
( 2,220)
( 1.35)
( 1,400)
( 1,045)
( 685)
72
415
0.76
215
160
105
( 182.9)
( 1,845)
( 1.94)
( 955)
( 710)
( 465)
Table 37- MT-20 Maximum Factored Column
Loads 1, 2, 6, 7, 8
Unbraced Height in( cm)
Max Factored Load at Channel Face lbs( N)
K = 0.65 lbs( N)
Maximum Column Load Applied at C. G.
K = 0.80 lbs( N)
K = 1.0 lbs( N)
K = 1.2 lbs( N)
12
2,520
6,290
6,290
6,290
6,290
( 30.5)
( 11,200)
( 27,985)
( 27,985)
( 27,985)
( 27,985)
24
2,790
6,290
6,290
6,175
5,340
( 61.0)
( 12,420)
( 27,985)
( 27,985)
( 27,475)
( 23,760)
36
2,410
6,290
5,340
4,260
3,395
( 91.4)
( 10,725)
( 27,985)
( 23,760)
( 18,955)
( 15,110)
48
1,985
4,960
3,950
2,965
2,380
( 121.9)
( 8,830)
( 22,060)
( 17,580)
( 13,190)
( 10,595)
60
1,590
3,880
2,965
2,275
1,800
( 152.4)
( 7,075)
( 17,255)
( 13,190)
( 10,115)
( 8,005)
72
( 182.9)
1,295
( 5,760)
3,065
( 13,635)
2,380
( 10,595)
1,800
( 8,005)
**
Notes:
1. Loads are based on ICC-ES ELC-5019 and CSA S136-16, the North American Specification for the Design of Cold-Formed Steel Structural Members( using the Appendix B provisions applicable to Canada), CSA Group.
2. Resistance factors for flexure and compression are 0.90 and 0.80, respectively.
3. Maximum factored beam loads in table are given in total uniform load( W * Span) and based on a uniformly loaded condition with simply supported ends. For other loading and support conditions, see page 32 for applicable load and deflection modification factors.
4. Beams spans in table are assumed to be sufficiently laterally braced. Unbraced spans may reduce beam load carrying capacity. See page 49 for reduction factors for unbraced conditions.
5. Profile weight, 0.84 lbs / ft( 12.26 N / m), must be deducted from maximum factored beam load values. 6. C. G. is the‘ Center of Gravity’ of the cross section. 7. ** indicates KL / r for compression exceeds 200. 8. Maximum factored load at channel face assumes K value of 0.8.
��������“) ��
����
��������“)
����“)
����
����
����“)
������“)
��
��������“) ��
�����
�����“)
���������
�����“ ���������“)
mm( in)
