Figure 10 — Influence of temperature on masonry bond strength 1 , 2
Allowable bond strength % of load at 70 ° F
Base material temperature ° F
1 Test procedure involves the concrete being held at the elevated temperature for 24 hours them removing it from the controlled environment and testing to failure .
2 Long term creep test in accordance with ICC-ES Acceptance Criteria AC58 .
INSTALLATION INSTRUCTIONS
Table 58 -Gel time 1 , 2 Base material temperature ° F ° C
HIT-ICE
– 10 – 23 1.5 h 0 – 18 1.5 h 20 – 7 1 h 40 4 15 60 16 5 min 70 21 2.5 min 90 32 1 min
Table 59 - Full cure time 1 , 2 Base material temperature ° F ° C
HIT-ICE
– 10 – 23 36 h 0 – 18 24 h 20 – 7 6 h 40 4 1.5 h 60 16 1 h 70 21 45 min 90 32 35 min
1 Product temperatures must be maintained above 0 ° F (– 18 ° C ) prior to installation .
2 Gel times and full cure times are approximate .
Installation Instructions For Use ( IFU ) are included with each product package . They can also be viewed or downloaded online at www . hilti . com ( US ), or www . hilti . ca ( Canada ). Because of the possibility of changes , always verify that downloaded IFU are current when used . Proper installation is critical to achieve full performance . Training is available on request . Contact Hilti Technical Services for applications and conditions not addressed in the IFU .
ORDERING INFORMATION
Description
Contents HIT-ICE Cartridge 10 oz ( 297 ml ) 24 Cartridges , 24 Mixers
HIT-ICE Cartridge
Description Notes Qty / Pkg MD 1000 Dispenser For use with HIT-ICE cartridges 1
MD 1000 Dispenser
Description Notes Qty / Pkg HIT-M2 Mixer for HIT-ICE only For use with HIT-ICE cartridges 1
HIT-ICE Mixer
HIT Filler Tube For ordering information on anchor rods and inserts , dispensers , hole cleaning equipment and other accessories , see section 3.2.9 .
HIT-ICE Mixer HIT-ICE Cartridge
HIT-ICE Dispenser
232 Anchor Fastening Technical Guide Edition 22 | 3.0 ANCHORING SYSTEMS | 3.2.5 HIT-ICE ADHESIVE ANCHORING SYSTEM Hilti , Inc . 1-800-879-8000 | en español 1-800-879-5000 | www . hilti . com | Hilti ( Canada ) Corporation | www . hilti . ca | 1-800-363-4458
