Installation instructions
Installation Instructions For Use( IFU) are included with each product package. They can also be viewed or downloaded online at www. hilti. com. Because of the possibility of changes, always verify that downloaded IFU are current when used. Proper installation is critical to achieve full performance. Training is available on request. Contact Hilti Technical Services for applications and conditions not addressed in the IFU.
Ordering instructions
Table 9. Hilti KB-TZ2 carbon steel product portfolio
Description
Length( in)
Length ident. letter
Thread length( in)
Nominal embed. 1( in)
Min. fixture thickness 1( in)
Max. fixture thickness 1( in)
Nominal embed. 2( in)
Min. fixture thickness 2( in)
Max. fixture thickness 2( in)
Nominal embed. 3( in)
Min. fixture thickness 3( in)
Max. fixture thickness 3( in)
Nominal embed. 4( in)
Min. fixture thickness 4( in)
Max. fixture thickness 4( in)
KB-TZ2 1 / 4 x 2-1 / 8 2-1 / 8 B 7 / 8 1-3 / 4 0 1 / 8--------- 100 KB-TZ2 1 / 4 x 2-1 / 2 2-1 / 2 C 1-1 / 4 1-3 / 4 0 1 / 2--------- 100 KB-TZ2 1 / 4 x 3-1 / 4 3-1 / 4 D 2 1-3 / 4 0 1-1 / 4--------- 100 KB-TZ2 1 / 4 x 4-1 / 2 4-1 / 2 G 3 1-3 / 4 1 / 8 2-1 / 2--------- 100 KB-TZ2 3 / 8 x 2-1 / 2 2-1 / 2 C 1 1-7 / 8 0 1 / 4--------- 50 KB-TZ2 3 / 8 x 3 3 D 1 1 / 2 1-7 / 8 0 3 / 4 2-1 / 2 0 1 / 4------ 50 KB-TZ2 3 / 8 x 3-1 / 2 3-1 / 2 Ω 2 1-7 / 8 0 1-1 / 4 2-1 / 2 0 3 / 4 3 0 1 / 4--- 50 KB-TZ2 3 / 8 x 3-3 / 4 3-3 / 4 E 2-1 / 4 1-7 / 8 0 1-1 / 2 2-1 / 2 0 1 3 0 1 / 2--- 50 KB-TZ2 3 / 8 x 5 5 H 3-1 / 2 1-7 / 8 0 2-3 / 4 2-1 / 2 0 2-1 / 4 3 0 1-3 / 4--- 50 KB-TZ2 3 / 8 x 7 7 L 4-7 / 8 1-7 / 8 1 / 2 4-3 / 4 2-1 / 2 0 4-1 / 4 3 0 3-3 / 4--- 50 KB-TZ2 1 / 2 x 3 3 D 1-1 / 8 2 1 / 4 1 / 2 2-1 / 2 0 0------ 20 KB-TZ2 1 / 2 x 3-3 / 4 3-3 / 4 E 1-5 / 8 2 1 / 2 1-1 / 4 2-1 / 2 0 3 / 4 3 0 1 / 4--- 20 KB-TZ2 1 / 2 x 4-1 / 2 4-1 / 2 G 2-3 / 8 2 1 / 2 2 2-1 / 2 0 1-1 / 2 3 0 1 3-3 / 4 0 1 / 4 20 KB-TZ2 1 / 2 x 5-1 / 2 5-1 / 2 I 3-3 / 8 2 1 / 2 3 2-1 / 2 0 2-1 / 2 3 0 2 3-3 / 4 0 1-1 / 4 20 KB-TZ2 1 / 2 x 7 7 L 4-3 / 4 2 5 / 8 4-1 / 2 2-1 / 2 1 / 8 4 3 0 3-1 / 2 3-3 / 4 0 2-3 / 4 20 KB-TZ2 1 / 2 x 8-1 / 2 8-1 / 2 O 4-7 / 8 2 2 6 2-1 / 2 1-1 / 2 5-1 / 2 3 1 5 3-3 / 4 1 / 4 4-1 / 4 20 KB-TZ2 1 / 2 x 10 10 R 4-7 / 8 2 3-1 / 2 7-1 / 2 2-1 / 2 3 7 3 2-1 / 2 6-1 / 2 3-3 / 4 1-3 / 4 5-3 / 4 20 KB-TZ2 5 / 8 x 4-1 / 4 4-1 / 4 F 2-1 / 4 3-1 / 4 0 3 / 8--------- 15 KB-TZ2 5 / 8 x 4-3 / 4 4-3 / 4 G 2-3 / 4 3-1 / 4 0 7 / 8 3-3 / 4 0 3 / 8------ 15 KB-TZ2 5 / 8 x 5-1 / 2 5-1 / 2 I 3-1 / 2 3-1 / 4 0 1-5 / 8 3-3 / 4 0 1-1 / 8 4-1 / 2 0 3 / 8--- 15 KB-TZ2 5 / 8 x 6 6 J 4 3-1 / 4 0 2-1 / 8 3-3 / 4 0 1-5 / 8 4-1 / 2 0 7 / 8--- 15 KB-TZ2 5 / 8 x 7 7 L 4-7 / 8 3-1 / 4 0 3-1 / 8 3-3 / 4 0 2-5 / 8 4-1 / 2 0 1-7 / 8--- 15 KB-TZ2 5 / 8 x 8-1 / 2 8-1 / 2 O 6-1 / 2 3-1 / 4 0 4-5 / 8 3-3 / 4 0 4-1 / 8 4-1 / 2 0 3-3 / 8--- 15 KB-TZ2 5 / 8 x 10 10 R 7-1 / 8 3-1 / 4 1 / 8 6-1 / 8 3-3 / 4 0 5-5 / 8 4-1 / 2 0 4-7 / 8--- 15 KB-TZ2 3 / 4 x 4-3 / 4 4-3 / 4 G 2-1 / 2 4 0 1 / 8--------- 10 KB-TZ2 3 / 4 x 5-1 / 2 5-1 / 2 I 3-1 / 4 4 0 7 / 8 4-1 / 2 0 3 / 8------ 10 KB-TZ2 3 / 4 x 6-1 / 4 6-1 / 4 J 3-1 / 4 4 0 1-5 / 8 4-1 / 2 0 1-1 / 8 5-1 / 2 0 1 / 8--- 10 KB-TZ2 3 / 4 x 7 7 L 4 4 0 2-3 / 8 4-1 / 2 0 1-7 / 8 5-1 / 2 0 7 / 8--- 10 KB-TZ2 3 / 4 x 8 8 N 5 4 0 3-3 / 8 4-1 / 2 0 2-7 / 8 5-1 / 2 0 1-7 / 8--- 10 KB-TZ2 3 / 4 x 9 9 P 6 4 0 4-3 / 8 4-1 / 2 0 3-7 / 8 5-1 / 2 0 2-7 / 8--- 10 KB-TZ2 3 / 4 x 10 10 R 7 4 0 5-3 / 8 4-1 / 2 0 4-7 / 8 5-1 / 2 0 3-7 / 8--- 10 KB-TZ2 1x6-1 / 2 6-1 / 2 K 2 1 / 2 4 5 / 8 0 1-1 / 8 6-3 / 8-------- 10 KB-TZ2 1x8 8 N 3 7 / 8 4 5 / 8 0 2-5 / 8 6-3 / 8 0 7 / 8------ 10 KB-TZ2 1x9 9 P 3 7 / 8 4 5 / 8 7 / 8 3-5 / 8 6-3 / 8 0 1-7 / 8------ 10 KB-TZ2 1x10-1 / 2 10-1 / 2 R 6 4 5 / 8 3 / 8 5-1 / 8 6-3 / 8 0 3-3 / 8------ 10 KB-TZ2 1x12 12 T 6 4 5 / 8 1-7 / 8 6-5 / 8 6-3 / 8 1 / 8 4-7 / 8------ 10
Pkg Qty
70
